- Page 1 Self-Contained Cubelet Ice Maker INSTRUCTION MANUAL PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER MODELS HP15CU-IL(-IR)(-2) - 15” Signature Series Cubelet Ice Maker HA15CU-IL(-IR)(-2) - 15” ADA Compliant Cubelet Ice Maker Form No. Z2547 Rev. 07.03.24 1A7613-010...
-
Page 2: Table Of Contents
For more information on whether a product in this list E. Condenser contains these chemicals, please refer to the specific product V. Preparing the Appliance for Periods of Non-Use page at perlick.com. Or to find out more about Prop 65, VI. Disposal go to P65Warnings.ca.gov. IMPORTANT This manual should be read carefully before the appliance is installed and operated. -
Page 3: Safety Considerations
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL SAFETY CONSIDERATIONS Indicates a hazard that WILL PLEASE READ all instructions completely before DANGER result in serious injury or death attempting to install or operate the unit. Take if precautions are not followed. - Page 4 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL , Continued WARNING • This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 5: Specifications
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS A. Construction Top Panel Ice Discharge Opening Bin Control Thermistor Scoop Holder Slope Front Panel Door Control Switch Power Cord Louver perlick customer service (800)558-5592 | 5... -
Page 6: Electrical And Refrigerant Data
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS B. Electrical and Refrigerant Data The nameplate provides electrical and refrigerant data. The nameplate is located inside the storage bin. For certification marks, see the nameplate. We reserve the right to make changes in specifications and design without prior notice. -
Page 7: Dimensions/Connections
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS C. Dimensions/Connections 1. HP15CU-1L(-1R) perlick customer service (800)558-5592 | 7... -
Page 8: Hp15Cu-2
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS 2. HP15CU-2 8 | perlick.com/residential-design-solutions... -
Page 9: Ha15Cu-1L(-1R)
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS 3. HA15CU-1L(-1R) perlick customer service (800)558-5592 | 9... -
Page 10: Ha15Cu-2
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL I. SPECIFICATIONS 4. HA15CU-2 10 | perlick.com/residential-design-solutions... -
Page 11: Installation Instructions
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS WARNING • The appliance must be installed in accordance with applicable national, state, and local codes and regulations. • Failure to install, operate, and maintain the appliance in accordance with this manual will adversely affect safety, performance, component life, and warranty coverage and may result in costly water damage. -
Page 12: Built-In Installation Site
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS 2. Built-In Installation Site NOTICE • Do not let the weight of the counter rest on the appliance. • Do not install the appliance in a corner where the door will interfere with other equipment or where the appliance cannot be pulled out for service. -
Page 13: Door
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS C. Door 1. HP15CU-2, HA15CU-2 a) Overlay Panel Fabrication and Attachment IMPORTANT The overlay panel must be crafted by a professional cabinet maker to ensure quality results. (1) Parts Ensure that all parts required for the overlay panel assembly are contained in the accessories bag. - Page 14 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS (2) Overlay Panel Specification Use the specification that applies to your appliance (HP15CU-2 or HA15CU-2) and the directions that follow to prepare your overlay panel. (a) HA15CU-2 HA15CU-2 Overlay Panel Specification Overlay Panel Height 29 17/32"...
- Page 15 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS (b) HA15CU-2 HA15CU-2 Overlay Panel Specification Overlay Panel Height 27 9/16" (700 mm) Overlay Panel Width 14 13/16" (376 mm) Overlay Panel Thickness 5/8" (16 mm) minimum; 3/4" (19 mm) maximum Overlay Panel and Door Weight (total) 20 lb.
- Page 16 Otherwise, the overlay panel cannot be properly fastened to the door. 4) Mount the door handle hardware. Perlick recommends that the door handle hardware be mounted on the edge opposite of the door hinge side (optional hinge reversal is covered in step 6.
- Page 17 II. INSTALLATION INSTRUCTIONS 6) If you would like to reverse the door hinges, do the following: a) Contact your local distributor to purchase a Perlick hinge kit. The kit contains "hinge (A)-left." b) Remove the 2 bolts securing the top panel, then lift it off. See Fig. 11.
- Page 18 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS 7) Remove the bushings from hinge (C1) and hinge (C2) (the hinges attached to the door). See Fig. 16. 8) Remove the gasket from the door. See Fig. 17. Bushing...
- Page 19 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS (4) Attachment of Overlay Panel to Door 1) Fasten the sheet metal bracket to the overlay panel using the two M4×8 truss head screws provided. Snug the screws, but do not tighten. See Fig. 20.
- Page 20 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS 7) Tighten the four M4×25 pan head screws installed in step 5. See Fig. 26. 8) Replace the door gasket in its proper orientation. Reinsert the bushings into hinge (C1) and hinge (C2) (the hinges attached to the door).
-
Page 21: Setup
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS D. Setup 1) Position the appliance in the selected permanent location. 2) Level the appliance from side-to-side and front-to-rear by adjusting the feet. 3) Insert the 4 canoe clips included in the accessory bag into the upper and lower holes on the inside of the door opposite from the door handle. -
Page 22: Electrical Connection
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS E. Electrical Connection WARNING • Electrical connection must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or damage. -
Page 23: Water Supply And Drain Connections
• External filters, strainers, or softeners may be required depending on water quality. Contact your local Perlick Certified Service Representative or local Perlick distributor for recommendations. • Connect to potable water supply only. Do not connect to a hot-water supply. - Page 24 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS Water Supply Inlet Minimum Water Supply Icemaker Drain Minimum Drain Line Line Size Outlet Size 1/2" Female Pipe 1/4" Nominal ID Copper 1/2" Female Pipe 1/2" Nominal ID Hard Thread (FPT)
- Page 25 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS c) Existing Drain Pipe Installation: When connecting to a suitable existing drain pipe (sink), the drain line must be installed in accordance with applicable national, state, and local codes and regulations. IMPORTANT! Confirm with local and state plumbing codes before connecting to an existing drain pipe.
-
Page 26: Final Checklist
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS G. Final Checklist WARNING CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin. 1. Pre-Startup... -
Page 27: Post-Startup
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL II. INSTALLATION INSTRUCTIONS 2. Post-Startup 1) During the first 5 minutes of the freeze cycle (compressor energized), confirm bin control operation by holding ice in contact with the bin control thermistor. The icemaker shuts down within 30 sec. -
Page 28: Operating Instructions
• This icemaker must be maintained in accordance with the instruction manual and labels provided with the icemaker. Consult with your local Perlick Certified Service Representative about maintenance service. • This icemaker must be cleaned and sanitized at least once a year. More frequent cleaning and sanitizing may be required in some water conditions. - Page 29 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL III. OPERATING INSTRUCTIONS NOTICE • Protect the floor when moving the icemaker to prevent damage to the floor. • Be aware of water left in the discharge pipe or hose in elevated drain line applications.
-
Page 30: Startup
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL III. OPERATING INSTRUCTIONS B. Startup WARNING All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. NOTICE • If the appliance is turned off, wait for at least 3 minutes before restarting the appliance to prevent damage to the compressor. - Page 31 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL III. OPERATING INSTRUCTIONS 7) Move the control switch to the "OFF" position. To reduce the risk of electric shock, do not touch the control switch or plug WARNING with damp hands. 8) Remove the ice produced, then clean the storage bin liner, door liner, and door gasket using a neutral cleaner.
-
Page 32: Maintenance
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE This icemaker must be maintained in accordance with the instruction manual and labels provided with the icemaker. Consult with your local Perlick Certified Service Representative about maintenance service. WARNING • Only qualified service technicians should service the appliance. -
Page 33: Maintenance Schedule
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE A. Maintenance Schedule The maintenance schedule below is a guideline. More frequent maintenance may be required depending on water quality, the appliance's environment, and local sanitation regulations. Maintenance Schedule Frequency Area... -
Page 34: Cleaning And Sanitizing Instructions
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE B. Cleaning and Sanitizing Instructions The appliance must be cleaned and sanitized at least twice a year. More frequent cleaning and sanitizing may be required in some conditions. WARNING • To prevent injury to individuals and damage to the appliance, do not use ammonia type cleaners. - Page 35 PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE 7) Make sure at least 10 minutes have elapsed since you poured the cleaning solution over the extruding head, then move the control switch to the "ICE" position. 8) Allow the appliance to make ice for 20 minutes, then move the control switch to the "DRAIN"...
-
Page 36: Storage Bin Drain
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE 5. Sanitizing Procedure - Final 1) Using a clean funnel and hose, pour 1 qt (1 l) of sanitizing solution over the extruding head. Allow the appliance to sit for 10 minutes before operation. -
Page 37: Drain Pump
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL IV. MAINTENANCE D. Drain Pump NOTICE Be aware of water left in the discharge pipe or hose in elevated drain line applications. 1) To test the operation of the drain pump and internal safety switch, move the control switch to the "ICE"... -
Page 38: Preparing The Appliance For Periods Of Non-Use
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL V. PREPARING THE APPLIANCE FOR PERIODS OF NON-USE During extended periods of non-use, extended absences, or in sub-freezing temperatures, follow the instructions below. When the appliance is not used for two or three days under normal conditions, it is sufficient to move the control switch to the "OFF"... -
Page 39: Disposal
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKER INSTRUCTION MANUAL V. PREPARING THE APPLIANCE FOR PERIODS OF NON-USE 14) Plug the appliance back in, then move the control switch to the "DRAIN" position. 15) Blow out the reservoir outlet hose using the compressed air or carbon dioxide supply. - Page 40 © 2024 Perlick Corporation 8300 West Good Hope Road, Milwaukee, WI 53223, USA perlick.com/residential • (800) 558-5592 Form No. Z2547 Rev. 07.03.24 1A7613-010...
