- Page 1 Luxury Operation & Installation Manual Signature Series (HP24- and HP48-inch models) Excludes Beer Dispenser Models HP24FS HP48RR HP24RS HP48RB HP24BS HP48WO HP24WS HP48WW Form No. Z2340 Rev. 06/04/2012...
-
Page 3: Table Of Contents
In the event you require assistance, products on the market. Perlick’s product offering gives you the please contact the dealer where you purchased your unit. -
Page 4: General Precautions
CAUTION Use only genuine Perlick replacement parts. Imitation parts can WARNING damage the unit, and may void the warranty. • Never attempt to repair or perform maintenance on the unit until the electricity has been disconnected. - Page 5 MILWAUKEE, WI 53223 3/4" to these dimensions " " " when fully extended. PRIN " PROPERTY OF THE PERLICK CORP. NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS Inside Drawer 4/12/2012 " 20" " J:\Dwg\95000\95005.slddrw (Top & Bottom) "...
- Page 6 50" Area in which Signature Series HP48 Models MILWAUKEE, WI 53223 electrical outlet must be located. 95006 PRINTED PROPERTY OF THE PERLICK CORP. 4/24/2012 NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS SHEET 1 OF 3 J:\Dwg\95000\95006.slddrw 12 1/4"...
-
Page 7: Preparing The Space
WARNING All Perlick units come equipped with a NEMA 5-15P 90° plug with A minimum of two people should lift the cabinet off the base to a minimum of 5-feet of cord extending beyond the rear of the prevent possible personal injury. -
Page 8: Anti-Tip Brackets
Operation & Installation Manual Signature Series (HP24 and HP48 models) ANTI-TIP BRACKETS Figure 5 - 24” Anti-Tip Kit Drawing WARNING Unit may tip forward if loaded racks/shelves are all pulled out at the same time. To prevent tipping and provide a stable installation, the unit must be secured in place with the anti-tip brackets provided with the unit. -
Page 9: Installation
Operation & Installation Manual Signature Series (HP24 and HP48 models) INSTALLATION Figure 7 - Leveling CAUTION Finished flooring should be protected with the appropriate material to avoid damage from moving the unit. If unit has been laid on its back or sides, place unit upright and allow minimum of 24 hours before connecting power. -
Page 10: Shelving
Operation & Installation Manual Signature Series (HP24 and HP48 models) TOE PLATE INSTALLATION When the unit is secured in place, install the louvered toe plate. Single Door Beverage Center Secure louvered toe plate by snapping the latch into the latch The single door unit comes with two full-extension black vinyl- catch on the unit. - Page 11 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 9- Toe Plate Wood Overlay Template...
- Page 12 Operation & Installation Manual Signature Series (HP24 and HP48 models) Adjusting Full-extension Shelving Figure 10- Tab location 1. Pull the shelf out to its farthest position. Locate the tabs in the middle of both extenders (Figure 10). Lift one tab up while pushing the opposite tab down and pull shelf out.
-
Page 13: Door Options
2. Insert lock body and attach with nut. customer. Lock installation drawings: All Perlick units accept any of the above door configurations and Refer to Figure 16 for Lock Installation on solid wood overlay panel are fully interchangable. (page 17). - Page 14 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 13 - Solid wood overlay panel template...
- Page 15 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 14 - Glass wood overlay panel template...
- Page 16 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 15 - Wood overlay drawer panel template...
- Page 17 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 16 - Lock installation, solid wood overlay door panel...
- Page 18 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 17 - Lock installation, wood overlay glass door panel...
- Page 19 Operation & Installation Manual Signature Series (HP24 and HP48 models) Figure 18 - Lock installation, wood overlay drawer panel...
-
Page 20: Wooden Wine Rack Trim Finishing
8” Scan the QR code to the right with ” your smart phone to watch a How-To video on how to install Wood Overlay panels onto Perlick doors, otherwise, ” follow the instructions below. ” x 0.312” deep ” outs 1. -
Page 21: Operation
When loading items into the unit, do not block internal louvers and fan guard openings or performance will be decreased. LIGHT BULB REPLACEMENT To replace a defective or burnt out light bulb, unscrew the bulb counterclockwise and replace with an identical 15-watt bulb or smaller (Perlick replacement bulb number 67026). - Page 22 Operation & Installation Manual Signature Series (HP24 and HP48 models) TEMPERATURE CONTROLLER Document No. Z2305 © 2011 24”, 48” & 72” Cabinet Installation / Operation Manual...
-
Page 23: Checking Product Temperature
After 24 hours, check the temperature of the water. Adjust the control settings if necessary. You Perlick unit is pre-set in order to achieve the recommended temperature range when installed in a 70°F ambient room temperature. -
Page 24: Maintenance
Operation & Installation Manual Signature Series (HP24 and HP48 models) CLEANING AND OTHER MAINTENANCE CAUTION CAUTION Shut off electricity to the unit before cleaning the condenser Do not use abrasive cleaners or cloths on any of the interior or and other routine maintenance. exterior surfaces or removable parts. - Page 25 • During periods of high humidity some condensation might appear on outside surfaces. The condensation will disappear when the humidity drops. Meanwhile, be sure doors are closing and sealing properly. If condensation persists, contact your Perlick Factory Authorized Service Center.
-
Page 26: Warranty
Use only genuine Perlick replacement parts and accessories. Genuine Perlick parts and accessories are designed to work correctly with Perlick products and offer superior service life. The use of non-Perlick parts can damage the unit and may void the warranty •... - Page 27 Perlick’s sole liability and your exclusive remedy under this warranty are set forth in the initial paragraph above.
- Page 28 ENTIRE PRODUCT - Full One Year Warranty: For one (1) year from date of original purchase, Perlick Corporation’s warranty covers all parts and labor to repair or replace any part of the product, which proves to be defective in material and workmanship.
