Mechanical Installation
Mounting instructions
Rotate the disc (2) and fit it against the retaining ring (3). Both items are included in every delivery.
The fixing screw (5) and lock washer (4) are not included in the delivery. The parts are dependent on the length and size of
the shaft. For further information refer to the mounting arrangement (see chapter 3.5 Mounting Arrangement).
3
3
e
Illustration 3.3 Axial Fastening
Illustration 3.4 Maximum Allowed Eccentricity of the Conveyor
Shaft
Type
OGD-30
OGD-35
OGD-40
Table 3.3 Dimensions of the Shaft and Disc
1) Key length required for b
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
NOTICE
Use grease to mount the OneGearDrive onto the shaft. For example, CASTROL Obeen Paste NH1, ARAL Noco Fluid or
similar. Use a key in the same material and quality as the hollow shaft.
10
Operating Instructions
Shaft
b
l
f
e
i
h
a
b
b
c
min
max
30
120
140
8
35
120
140
10
40
120
140
12
. Adapt the key length according to the shaft length used (b).
min
Danfoss A/S © 06/2014 All rights reserved.
d+0.2
x
Dimensions [mm]
Shaft
d
e
1)
g
h
f
4
5
100
M10
22
5
5
100
M12
28
5
5
100
M16
36
Disc
edges cut
b
max
b
min
i
k
l
m
n
30
3
1.5
38
4
37
3
1.5
43
4
45
3
2
48
4
n
Disc
o
p
29.8
11
34.8
13
39.8
17
MG75C402
