Electrical Installation
®
4.5 CleanConnect
Connection Diagram
Illustration 4.4 shows the connection power plug for OneGearDrive Hygienic DA09LA10 in Y-connection with thermistors.
®
Illustration 4.4 CleanConnect
Description
Motor winding
Protective earth
1)
Temperature protection
KTY 84-130
®
Table 4.3 CleanConnect OneGearDrive Connection
®
1) When connected to VLT AutomationDrive FC 302 and VLT
information about parameter setting and programming, refer to the corresponding operating instructions.
T1
KTY 84-130
T2
Table 4.4 Connections T1 and T2
1) Only if connected

4.6 Overload Protection

Take note of the relevant circuit diagram for motors with thermally activated winding protection (see chapter 4.4 Cage
Clamp Connection Diagram).
Avoid automatic resetting after the winding has cooled.
The output of the motors is normally adequately rated. The rated current does not represent a measure of gear unit
utilisation in these cases and cannot be used as overload protection for the gear unit. In some cases, the way in which the
driven machine is loaded can exclude any overloading as a matter of course. In other cases, it is necessary to protect the
gear unit by mechanical means (e.g. slip clutch, sliding hub etc.). This depends on the maximum permissible limit torque
M in continuous running duty specified on the nameplate.
LT
MG75C402
Operating Instructions
V1 W1
U1
OneGearDrive Connection
Inverter output Pin
U 1
V 3
W 4
PE 2
T1 A
T2 B
®
Decentral Drive FCD 302, use analog input terminal 54, KTY sensor 1. For
®
1)
VLT AutomationDrive FC 302
Danfoss A/S © 06/2014 All rights reserved.
V
D
W
3
C
4
2
B
T1
1 A
T2
U
Typical cross-section
2
1.5 mm /AWG 16
2
1.5 mm /AWG 16
0.75 mm 2 /AWG 20
®
VLT Decentral Drive FCD 302
KTY sensor 1
Analog input 54
Maximum cross-section
2
2.5 mm /AWG 14
2
2.5 mm /AWG 14
1.5 mm 2 /AWG 16
1)
4 4
