1.4.2

G/P-3U-20-40V - Assembly Instructions for three 20V-40V units in Parallel

1.4.2.1 Components List


10‐32 x 5/16 Pan Head Screw, Stainless Steel

Helical Spring‐Lock Washer, No. 10, Stainless Steel

Plain Washer, No. 10, Stainless Steel

Connection Plate 3U

Output Short

M3 x 4C Flat Head Screw, Nickel Plated

Paralleling Cable

Output Cover

Component

Quantity
