TDK-Lambda GENESYS Series Instruction Manual page 2

Programmable dc power supplies, g1.7 - 5kw in 1u 0-600v, 0-500a, parallel kit

Hide thumbs Also See for GENESYS Series:

1.1

General

Parallel kit is supplied separately from the power supply packing according to order.

The usage of parallel kit is according to customer's needs.

1.2

Advanced Parallel

For parallel connection, refer to advanced parallel chapter in the

1.3

Product Safety Instructions

Safety approvals are valid for

When using a paralleling kit with a protective bracket, it must be correctly assembled, as described

further in this document.

1.4

Assembly Instructions

The supplied kit is used for standard and blank panel options. Follow the instructions carefully

according to power supply model.

1.4.1

G/P-3U-10V - Assembly Instructions for three 10V units in Parallel

1.4.1.1 Components List


10‐32 x 5/16 Pan Head Screw, Stainless Steel

Helical Spring‐Lock Washer, No. 10, Stainless Steel

Plain Washer, No. 10, Stainless Steel

Connection Plate 3U

Output Short

single unit only. These are not valid for parallel kit assembly.

Component

series User Manual.

Quantity
