TECHNICAL SPECIFICATION

Model
Power supply
Volts/phase frequency
Motor enclosure
Type of motor
Max. power consumption
Full load current
Rating
Max. No starts per hour
Min. inlet head
Max. inlet head
Max. head (Closed Valve)
Max. working pressure*
Max. ambient air temperature
Max. water temperature**
Min. water temperature
Cut out flow
Cut in pressure
Vessel pre-charge
Length (max)
Width (max)
Height (excluding flexible hoses)
Gross Weight Packed (including
accessories)
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
Note: For information on other voltages/frequencies which are not shown, consult
any supplementary instruction sheet supplied, or the rating label attached to
the pump.
Maximum permissable water temperature 65°C.
*Note: Max working pressure is the maximum pressure that can be applied to the
pump internal casing under any installation conditions.
**Note: In normal circumstances the temperature of stored water should never exceed
65°C. A stored water temperature of 60°C is considered sufficient to meet all
normal requirements and will minimise deposition of scale in hard water areas.
N1.3 bar N2.4 bar
230/1/50 230/1/50
IPX4 IPX4
Induction Induction
425 Watts 880 Watts
1.9 Amps 3.9 Amps
Continuous (S1) Continuous (S1)
60 60
1 metre 1 metre
8 metres 10 metres
14.2 metres 30.4 metres
500 kPa (5.0 bar) 400 kPa (4.0 bar)
40°C 40°C
65°C 65°C
4°C 4°C
1 l/min (approx) 1 l/min (approx)
80 kPa (0.8 bar) 140 kPa (1.4 bar)
89 kPa (0.89 bar) 89 kPa (0.89 bar)
291 mm 344 mm
165 mm 227 mm
356 mm 444 mm
9.0 Kg 11.7 Kg
- 16 -
N2.9 bar N3.7 bar
230/1/50 230/1/50
IPX4 IPX4
Induction Induction
1130 Watts 1060 Watts
5.2 Amps 4.9 Amps
Continuous (S1) Continuous (S1)
60 60
1 metre 1 metre
10 metres 10 metres
32.1 metres 47 metres
420 kPa (4.2 bar) 600 kPa (6.0 bar)
40°C 40°C
65°C 65°C
4°C 4°C
1 l/min (approx) 1 l/min (approx)
140 kPa (1.4 bar) 140 kPa (1.4 bar)
89 kPa (0.89 bar) 89 kPa (0.89 bar)
368 mm 443 mm
227 mm 231 mm
444 mm 447 mm
12.9 Kg 12.55 Kg
