Stuart Turner Monsoon Extra Installation Instructions Manual page 11

Wiring of connection unit
WARNING: This appliance must be earthed.
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow: Earth
As the colours of the wires in the mains lead of this appliance may not correspond with
the coloured markings identifying the terminals in your connection unit proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal in the
connection unit which is marked with the letter E or by the earth symbol:
green or green and yellow.
The wire which is coloured blue must be connected to the terminal which is marked with
the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked
with the letter L or coloured red.
Wiring Diagrams
The supply cord and internal wiring within the terminal box are routed
and secured to ensure compliance with the electrical standard EN60335-1.
It is essential that any disturbance of this internal wiring is avoided and the
factory routing and securing of all internal wiring is always maintained.
A M
N S1 S2 S3 S3 S2
N
E
Monsoon Extra N1.3 bar Single
Fig. 12
Fuses
The following fuse size should be used with the appropriate pump:
Model
Monsoon Extra N1.3 bar
All other models
MAIN WINDING
BLUE
THERMOTRIP
CAPACITOR
START WINDING
FLOWSWITCH
REED (S3)
PRESSURE
SWITCH (S1)
L
S1
230 VAC/1PH/50Hz
SUPPLY
L
Fuse Size (Amps)
Blue: Neutral
GREEN/YELLOW
BLUE
BROWN
N S1 S2 S3 S3 S2
N
E
230 VAC/1PH/50Hz SUPPLY
Monsoon Extra N2.4, N2.9 & N3.7 bar Single
5
13
- 11 -
Brown: Live
CAPACITOR
S1 L
FLOWSWITCH
REED
PRESSURE
SWITCH
L
Fig. 13
or coloured
MOTOR
