Customizing a Wire or Stylet

Once any wire is selected, the Customize button will become available.
To customize a wire or stylet:
1. Select a tool from the Tool Selection panel
The
Customize
button
2. Click Customize
The selected tool, in its default 2-D shape will appear on the left monitor.
A bending
point
3. Right-click on the bending points
Note: The bending points are indicated by green balls.
PN: 905K400652
The Simulation Screen - Tool Selected
The Customize Screen - 2D Image
Using the Simulator
A bending
point
41
