Selecting a Tool

The CathLabVR offers a selection of multiple tools for successfully completing a procedure. Users
select the tools from the hardware (wires, catheters, etc.) that they deem appropriate for the task
they chose and identify the selected tool in the software.
To select a tool in the software:
1. From the simulation screen left monitor, choose a tool pod in the tool selection panel
The feature
options list
The tool
selection
panel
The C-Arm
coordinates
The C-Arm
glyph
The options
panels
The filter
results panel
