Using the Simulator
The left monitor displays the tool selection panel, C-Arm glyph and coordinates, and the
feature options list: Physio, Cine, Still and Case History.
The feature
options list
The tool
selection
panel
The C-Arm
coordinates
The C-Arm
glyph
Note: Be sure to observe the content on both monitors while performing procedures.
When learners choose a feature from the features list, the content populates the left
monitor.
26
The Simulation Start Screen - Left Monitor
CAECathLabVR
PN: 905K400652
