Refer to the Module Identification illustrations to guide you through the
installation process.
Module Identification
Network Connectors
In and Out, 5-pin,
Micro (M12),
Reverse Keyway
Station
Address
Switches
Auxiliary Power
Connector, 5-pin,
Mini
Install the Module
To install the module:
• Mount the adapter and I/O bases
• Wire the adapter
PWR
Publication
Pro fib us DP
43790
1738-IN015C-EN-E - February 2010
5
