Installation Instructions DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module Catalog Number 1732D-8X81212D Topic Page Important User Information Environment and Enclosure Prevent Electrostatic Discharge About the Module Install the Module Mount the Module Communicate with Your Module Interpret the Status Indicators Specifications...
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 3 Environment and Enclosure This equipment is intended for use in overvoltage Category II applications (as ATTENTION defined in IEC 60664-1), at altitudes up to 2000 meters (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
4 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module About the Module The DeviceNet 1732D ArmorBlock I/O family consists of stand-alone 24V DC I/O modules that communicate via the DeviceNet network. The sealed IP69K housing of these modules requires no enclosure. Note that it is possible that environmental requirements other than IP69K require an additional appropriate enclosure.
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 5 Catalog Number Explanation The catalog number 1732D-8X81212D identifies a DeviceNet 24V DC 8-port 8-input 8-output 0.5…4.0 A M12-style network connector module. Install the Module To install the module: • Set the node address •...
6 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module To reset the node address: 1. Rotate the switches using a small blade screwdriver. 2. Line up the small black dot on the switch with the number setting you wish to use. 3.
Page 7
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 7 Product Dimensions Refer to the mounting dimensions illustration to help you mount the module. Module Dimensions 65 mm 43.25 mm (2.56 in.) (1.70 in.) 26.5 mm (1.04 in.) DNet In DNet Out I - 0 O - 0 I - 1...
Page 8
8 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module Mounting the Module in High Vibration Areas If you mount the module in an area that is subject to shock or vibration, we recommend that you use a flat and a lock washer to mount the module. Mount the flat and the lock washer as shown in the mounting illustration.
Page 9
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 9 Network Connector Refer to the pinout diagram for the network connector. M12-style Input Connectors Male Female (View into Connector) Pin 1 Drain Pin 2 V+ (Red) Pin 3 V- (Black) Pin 4 CAN_H (White) Pin 5 CAN_L (Blue)
Page 10
Pin 4 Output Power- 43906 Refer to publication M116-CA001 for Rockwell Automation cable and cord set offerings or access the Connection Systems website at http://www.ab.com/sensors/products/connection_systems/. If any I/O devices connected to this equipment require Class 2 power to ATTENTION operate, this equipment and all connected I/O must be powered by a Class 2 source.
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 11 Communicate with Your Module This module’s I/O is exchanged with the master through a cyclic, polled, or change-of-state connection. Cyclic - allows configuration of the block as an I/O client. The block will produce and consume its I/O cyclically at the rate configured.
12 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module Interpret the Status Indicators This module has the following status indicators: • Network and Module status indicator for DeviceNet • Auxiliary Power indicator • Individual I/O status indicators for inputs and outputs DNet In DNet Out Network status...
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 13 Device Status Indicators Indicator Status Description Network Device is not online. status - Device has not completed dup_MAC-id test. - Device not powered – check module status indicator. Green Device operating normally and is online with connections in the established state.
14 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module Specifications DeviceNet 1732 ArmorBlock Network Powered Input Auxiliary Powered Output Module, Series A - 1732D-8X81212D Inputs Attribute Value Number of inputs Off-state input voltage, max 5V DC On-state input voltage, max 25V DC On-state input voltage, nom 24V DC...
Page 15
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 15 DeviceNet 1732 ArmorBlock Network Powered Input Auxiliary Powered Output Module, Series A - 1732D-8X81212D Outputs Attribute Value Number of outputs On-state output voltage drop, max 0.5V DC Off-peak blocking voltage, min 30V DC On-state output voltage, max 30V DC...
Page 16
16 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module General Specifications (Continued) Attribute Value DeviceNet power voltage, min 11V DC DeviceNet current 100 mA plus sum of sensor currents Sensor source current per module, 500 mA Communication rate 125 Kbps @ 500 m (1640 ft) for thick cable, flat media length 375 m (1230 ft) 250 Kbps @ 200 m (600 ft) for thick cable, flat media length 150 m (492 ft)
Page 18
18 DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module Environmental Specifications (Continued) Attribute Value EFT/B Immunity IEC 61000-4-4: ±3 kV at 5 kHz on power ports ±3 kV at 5 kHz on signal ports ±2 kV at 5 kHz on communications ports Surge transient IEC 61000-4-5: immunity...
Page 19
DeviceNet ArmorBlock Network and Auxiliary Powered I/O Module 19 Certifications Certification (when Value product is marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E322657. European Union 2004/108/EC EMC Directive, compliant with: EN 61326-1; Meas./Control/Lab., Industrial Requirements EN 61000-6-2;...
Page 20
New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
