Page 1: Table Of Contents
Installation Instructions ArmorPoint PROFIBUS Adapter, Series A Catalog Number 1738-APB Inside . . . See Page Important User Information Environment and Enclosure Prevent Electrostatic Discharge About the ArmorPoint PROFIBUS Adapter Install the Module Set the Station Address Troubleshoot Specifications Publication 1738-IN015C-EN-E - February 2010... -
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Environment And Enclosure
Environment and Enclosure This equipment is intended for use in overvoltage Category II ATTENTION applications (as defined in IEC publication 60664-1), at altitudes up to 2000 meters without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11. Without appropriate precautions, there may be potential difficulties ensuring electromagnetic compatibility in other environments due to conducted as well as radiated disturbance. -
Page 4: Prevent Electrostatic Discharge
Prevent Electrostatic Discharge This equipment is sensitive to electrostatic discharge, which can ATTENTION cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. • Wear an approved grounding wriststrap. •... -
Page 5: Install The Module
Refer to the Module Identification illustrations to guide you through the installation process. Module Identification Network Connectors In and Out, 5-pin, Micro (M12), Reverse Keyway Station Address Switches Auxiliary Power Connector, 5-pin, Mini Pro fib us DP 43790 Install the Module To install the module: •... - Page 6 Mount the Adapter and I/O Bases To mount the ArmorPoint adapter on a wall or panel, use the screw holes provided in the ArmorPoint adapter. Drilling Dimensions Adapter 20.1 mm 20.1 mm (0.8 in) (0.8 in) 46.25 mm 51.9 mm 51.9 mm 51.9 mm (1.8 in)
-
Page 7: Set The Station Address
Terminating Bases Mounting Hole Ground Connection 43787 Latching Mechanism Set the Station Address To set the station address, adjust the switches on the front of the module (refer to the Module Identification illustration). Use a small blade screwdriver to rotate the switches. Line up the small notch on the switch with the number setting you wish to use. - Page 8 GSD File Requirements Current functionality of PROFIBUS adapters requires GSD files. These files are easy to install and are available online at: www.ab.com/networks/gsd/. Wire the Adapter Refer to the illustrations for wiring instructions for the adapter. PROFIBUS In, Male, 5-pin Micro (M12), Reverse Keyway Female Out Male In (View into Connector)
-
Page 9: Troubleshoot
Troubleshoot To help you troubleshoot the adapter, refer to the Troubleshoot with the Indicators illustration and the individual indicator troubleshooting tables. Troubleshoot with the Indicators Adapter Status Indicator Profibus Status Indicator PointBus Status Indicator System Power Indicator Adapter Power Indicator 43790 Publication 1738-IN015C-EN-E - February 2010... - Page 10 Adapter Status Indicator Refer to the table for a description of the Adapter Status indicator. Adapter Status Indicator State Status Description Recommended Action • No power supplied. Off or Turn the adapter on or wait until the Process in hardware check or initialization has •...
- Page 11 PROFIBUS Status Indicator Refer to the table for a description of the PROFIBUS Status indicator. PROFIBUS Status Indicator State Status Description Recommended Action • No power supplied. Off or Bus Turn the adapter on or Offline go online with the Bus. •...
- Page 12 PointBus Status Indicator Refer to the table for a description of the PointBus Status indicator. PointBus Status Indicator State Status Description Recommended Action • No power supplied. Off or Turn the adapter on or wait until the Process in hardware check or initialization has •...
- Page 13 System Power Indicator Refer to the table for a description of the System Power indicator. System Power Indicator State Status Description Recommended Action System Power System power is not Apply power. Not Applied applied. Green System Power System power (5V) is None.
-
Page 14: Specifications
Specifications ArmorPoint PROFIBUS Adapter - 1738-APB Specifications Specification Value • PROFIBUS adapter backplane current output = 1.0 A max Expansion I/O Capacity See the list of catalog numbers below for backplane current consumption and the current consumption for ArmorPoint modules connected to the ArmorPoint PROFIBUS adapter. - Page 15 ArmorPoint PROFIBUS Adapter - 1738-APB Specifications Field Power Bus Nominal Voltage 24V dc Supply Voltage 10…28.8V dc range Supply Current 10 A max Field Side Power 24V dc (+20% = 28.8V dc) @ 400 mA Requirements, Max Input Overvoltage Protection Reverse polarity protected Input Voltage Rating 24V dc nom 10…28.8V dc range...
- Page 16 ArmorPoint PROFIBUS Adapter - 1738-APB Specifications Power Consumption, Max 8.1 W @ 28.8V dc Power Dissipation, Max 2.8 W @ 28.8V dc Thermal Dissipation, Max 9.5 BTU/hr @ 28.8V dc Weight Metric 0.36 kg Weight Imperial 0.80 lb 1 - on signal ports Wiring Category 1 - on communications ports Use this Conductor Category information for planning conductor routing.
- Page 17 Environmental Specifications Radiated RF Immunity IEC 61000-4-3: 10V/m with 1 kHz sine-wave 80%AM from 30…2000 MHz 10V/m with 200 Hz 50% Pulse 100%AM at 900 Mhz 10V/m with 200 Hz 50% Pulse 100%AM at 1890 Mhz EFT/B Immunity IEC 61000-4-4: ±4 kV at 5 kHz on power ports ±2 kV at 5 kHz on communications ports Surge Transient Immunity...
