ArmorPoint PROFIBUS Adapter - 1738-APB Specifications
Power Consumption, Max
Power Dissipation, Max
Thermal Dissipation, Max
Weight Metric
Weight Imperial
(1)
Wiring Category
(1)
Use this Conductor Category information for planning conductor routing. Refer to
Publication 1770-4.1, Industrial Automation Wiring and Grounding Guidelines.
Environmental Specifications
Specification
Operating Temperature
Storage Temperature
Relative Humidity
Shock, Operating
Shock, Non-operating
Vibration
ESD Immunity
Publication
1738-IN015C-EN-E - February 2010
8.1 W @ 28.8V dc
2.8 W @ 28.8V dc
9.5 BTU/hr @ 28.8V dc
0.36 kg
0.80 lb
1 - on signal ports
1 - on communications ports
Value
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...60 °C (-4...140 °F)
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
-40...85 °C (-40...185 °F)
IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp
Heat):
5...95% non-condensing
IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
IEC60068-2-27 (Test Ea, Unpackaged Shock):
50 g
IEC60068-2-6 (Test Fc, Operating):
5 g @ 10...500 Hz
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
