5.3 PROCESS

WARNING Moderate risk of serious injury through electric shocks
While using the SMARTneo-2G, liquid intrusion may lead to serious injury through
electric shocks.
• Ensure components are placed away from areas where spillages may occur
• Take care not to spill liquids onto or around the Control Box
LOGICDATA does not restrict customers to specific mounting positons for the SMARTneo-
NOTICE
2G. However, mounting the Control Box incorrectly may cause the Light Barrier colli-
sion detection system to malfunction. To ensure correct installation, all Table Tops must
be tested thoroughly (different materials, thicknesses, etc.). Additionally:
• Ensure there is no gap between the SMARTneo-2G and the Table Top at the mount-
ing points. The Control Box must be tightly secured with no movement possible.
• Ensure the mounting surface is smooth, flat, and undamaged.
• Ensure the entire housing of the SMARTneo-2G is placed underneath the Table Top.
• Ensure the Control Box is installed and used within the ambient conditions speci-
fied in the product datasheet.
• If the Light Barrier function is not working properly, contact LOGICDATA.
NOTICE
LOGICDATA recommends using the drilling template on page 13 to mark the positions
of the Mounting Screws. If you choose not to do so, pay close attention to the dimen-
sions of the SMARTneo-2G.
1. Position the SMARTneo-2G under the table top and mark the position of the drilling holes. If
necessary, use the Drilling Template on page 13 to help you.
2. Drill the holes into the table top.
3. Use the screwdriver and 2 Mounting Screws to attach the SMARTneo-2G to the Table Top at the
drilled holes.
The required tightening torque depends on the material of the Table Top. Do not exceed
NOTICE
2 Nm.

5.4 COMPLETING ASSEMBLY

After the SMARTneo-2G is attached to the Table Top, you must connect the Control Box to the system.
Instructions for this can be found in the next chapter.
