5 ASSEMBLY

This chapter of the Operating Manual describes the process of mounting the SMARTneo-2G to the Table
Top. You must read the documentation for each part of the system (Actuator, User Interface, Power Unit,
etc.) for that product's mounting instructions. Instructions for connecting the system's components to the
SMARTneo-2G can be found in Chapter 6, Connecting the System).
5.1

SAFETY DURING ASSEMBLY

Risk of minor or moderate injury through improper handling
CAUTION
Improper handling of the product during assembly may lead to minor or moderate in-
jury through cutting, pinching, and crushing.
• Avoid contact with sharp edges
• Be careful while handling tools that may cause personal injury
• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing
• Read all instructions and safety advice carefully
Risk of minor or moderate injury through tripping
CAUTION
During assembly and operation, poorly routed Cables may become a trip hazard.
Tripping over Cables may lead to minor or moderate injury.
• Ensure that Cables are routed properly to avoid trip hazards
• Be careful not to trip over Cables when installing the Hand Control
Ensure proper ESD handling during assembly. Damage that can be attributed to electro-
NOTICE
static discharge will void warranty claims.
NOTICE
Before assembly, all parts must be acclimatised to the ambient conditions.
Perform a product risk assessment so that you can respond to potential residual haz-
INFO
ards. Assembly instructions must be included in your end user Operating Manual

5.2 REQUIRED COMPONENTS

SMARTneo-2G Control Box
1
2 Mounting Screws (supplied by Reseller)
2
Drill or drilling machine
Tool
Screwdriver
Tool
Screw specifications
INFO
The mounting points for the SMARTneo-2G have a diameter of 5.5 mm. The Mounting
Screws should hold the SMARTneo-2G safely and securely in place. Exact specifications
can be provided by LOGICDATA on request.
