LOGICDATA SMARTneo-2G Manual page 30

E60 ISP Activated
E61 Motor Replaced
E65 Overcurrent while driving
E67 High Voltage Detected
E70 Motor Configuration Changed
E71 Collision Sensor Defective
E72 Position Error (Middle Switch*)
E73 Middle Switch* Defective
E81 Internal Error
E90
E91 Cascading error (slave)
E92
Connection Error During
E93
Cascading
Do not operate the table system if problems persist. Contact LOGICDATA for further
NOTICE
information.
The Middle Switch is only fitted to certain versions of the SMARTneo-2G. Contact
NOTICE
LOGICDATA if you are unsure which version you have.
SMARTNEO - OPERATING MANUAL // PAGE 30
Release all Keys and wait for the Drive Back function to be
completed.
Plug in the correct motor. Ensure all cables are connected
correctly. Perform a Factory Reset. Perform a Position Reset
Procedure.
Check that nothing is blocking the table's range of movement.
Remove excess load from the table. Contact LOGICDATA for
further information.
Disconnect the Control Box from the Mains.
LOGICDATA for further information.
Disconnect the Control Box from the Mains. Connect the
Actuators in the desired setup. Perform a Factory Reset.
Perform a Position Reset Procedure. Read Chapter 9,
"Actuator Setup", for advice on changing Actuator types.
Perform a Factory Reset. Contact LOGICDATA if the problem
persists.
Disconnect the Control Box from the Mains. Wait for at
least 20 seconds. Reconnect and perform a Position Reset
Procedure.
Disconnect the Control Box from the Mains.
LOGICDATA for further information.
Disconnect the Control Box from the Mains. Restart and per-
form a Factory Reset. Contact LOGICDATA for further infor-
mation if the problem persists.
Check all connections. Attempt a Position Reset Procedure.
If this is not possible, disconnect all Control Boxes from the
Mains and try again. Contact LOGICDATA for further infor-
mation if the problem persists.
Check all connections. Attempt a Position Reset Procedure.
If this is not possible, disconnect all Control Boxes from the
Mains and try again. Contact LOGICDATA for further infor-
mation if the problem persists.
Contact
Contact
