1.
The handling of the system assumes knowledge of the instruction manual.
1.1
The following symbols are used in this instruction manual:
i
1.2
Connect the power supply according to the safety regulations for electrical operating equipment.
> Danger of injury
> Damage to or destruction of the sensor
The supply voltage must not exceed specified
limits.
> Damage to or destruction of the sensor
Avoid banging and knocking the sensor.
> Damage to or destruction of the sensor
Avoid bending the sensor rod or the alu tube.
> Damage to or destruction of the sensor
Do not transport the sensor on the sensor rod.
> Damage to or destruction of the sensor
induSENSOR, EDS
Safety
Symbols Used
Indicates a hazardous situation which, if not avoided, may result in minor or moder-
ate injury.
Indicates a situation which, if not avoided, may lead to property damage.
Indicates a user action.
Indicates a user tip.
Warnings
Sensor-
Sensor rod
housing
Alu tube
Sensor
housing
Page 5
