SECTION 3 - KEYPAD/DISPLAY: DESCRIPTION AND FUNCTION
5
6
7
8
Figure 1. ROYTRONIC EXCEL™ Series AD9 Control Panel
3.1

POWER BUTTON

The POWER button turns the pump ON or OFF.
If the pump is not running, pressing this button will
cause the pump to start running. If the pump is
running, pressing the
the pump. The POWER button is also used to
prime the pump as described in Sec. 4.3. When
in a programming screen or a selection menu, the
POWER button is generally used to enter/select
the associated item.
3.2

MODE SELECTION BUTTON

The MODE button is used to enter the main
selection menu. The
often be used to exit the current programming
menu. Details of its use will be covered in greater
detail later in this supplement.
POWER button will stop
MODE button can also
Instruction Manual
4
1. POWER Button
2. MODE Button
3
3. DOWN Button
2
4. UP Button
5. Graphical Display
1
6. Stroke Adjustment Knob
7. Pump ON/OFF LED
8. Low-Level Indicator LED
3.3 UP AND
The UP and
change parameters (i.e. stroke frequency) as
well as to navigate the selection menus. These
functions are covered in greater detail later in this
supplement.
DOWN BUTTONS
DOWN buttons are used to
3
