SECTION 6 - ADVANCED CONFIGURATION MENU
6.10 SET PERCENT-OF-TIME
OPERATION
This feature allows time-based cycling of the
pump in Manual, Pulse Divide, and Analog Control
Modes. The pump cycles on and off based on
the configuration parameters. Use the
DOWN button to select the
POWER button to toggle the Function Enabled
Indicator. Use the
parameter's edit mode (Percent of Time and Cycle
Duration parameters). While in edit mode, use the
UP and DOWN buttons to set the value. Use
the MODE button to return to the advanced
configuration menu.
Example: Editing Percent-of-Time Parameter
26
icon. Use the
POWER button to toggle the
Instruction Manual
Display Overview:
Function Enabled
Indicator
Percent-of-Time
UP or
1. Function Enabled Indicator: Indicates if
Percent-of-Time functionality is enabled.
Off
= Function OFF / Disabled.
= Function ON / Enabled.
On
2. Percent of Time (Function ON only): Percent
of time cycle to enable pump stroking (0-100).
3. Cycle Duration (Function ON only): Total
cycle time in minutes (1-1440).
4. Selection Box: Indicates the currently selected
item.
For example, if
will cycle continuously as follows: run for 2 minutes,
stop for 8 minutes. When this feature is enabled,
the icon is displayed in the Icon/Alarm area of
the display (see Sec. 4.5).
Selection Box
Cycle Duration
= 20 and = 10, then the pump
