Kirsch Cellular Shade Collection Getting Started page 6

Attach the spacer blocks and installation brackets with #6 hex head mounting screws long
■ ■
enough for a secure installation. (See chart below.) Longer screws are not provided.
The top of the spacer blocks should be at the desired shade height.
➤ ■
The front edges of the installation brackets must be level and aligned to each other.
➤ ■
CAUTION: Use drywall anchors when mounting into drywall.
CAUTION: The rear of the spacer blocks must be flush against a flat surface. Do not mount
spacer blocks and installation brackets on curved molding.
IMPORTANT: The provided 1
will need to supply longer screws if additional clearance is required.
A minimum 1 ⁄ " length of screw threads must extend beyond the last spacer block or shim. Use
1
4
appropriate wall anchors when mounting into drywall.
Mount the Headrail
Mount the headrail into the installation brackets. Do not remove any components from the headrail. Both end plates should remain
■ ■
attached to the ends of the headrail.
Carefully align the headrail with the end marks on the mounting surface. Headrail position cannot easily be adjusted after
➤ ■
the headrail is mounted. (Remember that the end of the gear box is the end of the headrail on the stacking side.)
Place the front groove on the headrail onto the front lip of the installation brackets.
➤ ■
Rotate the rear of the headrail up and push back until the headrail snaps in place.
➤ ■
Align End of
Gear Box with
End Mark
INSTALLATION
INSTALLATION
⁄ " screws can only be used with a maximum of one
1
2
Shim
1 " Minimum
1
4
Maximum of One
Shim with Provided
1 " Screws
1
2
Align Headrail with End Marks
Proceed to "Install the Fabric Stack" on page 7.
⁄ " shim. You
1
8
2" (Not provided; up to
5
8
2 " (Not provided; up to 1
1
2
3" (Not provided; up to 1
1
Never use more than 1 " of spacer blocks/shims!
1
2
Place Groove onto
Front of Bracket
5
Maximum
1 "
1
2
Longer Screw
(Not Provided)
" of spacer blocks/shims)
⁄ " of spacer blocks/shims)
1
8
" of spacer blocks/shims)
2
Snap in
Place
