Kirsch Cellular Shade Collection Getting Started page 5

Determine where to place the top of the installation brackets.
■ ■
Add the desired floor clearance to the ordered height of the shade. The ordered height can
➤ ■
be found on the packaging label. A minimum of
Measure the total distance up from the floor. This is where to place the top of the installation brackets.
➤ ■
A minimum flat vertical surface of 1
➤ ■
CAUTION: The rear of the brackets must be flush against a flat mounting surface. Do not
mount brackets on curved molding.
Center the brackets on your marks and mark the screw holes.
■ ■
When using extension brackets, mark two screw holes
➤ ■
per bracket.
Drill the screw holes using a
■ ■
CAUTION: Use drywall anchors when mounting into drywall. Use
the drill bit size recommended by the manufacturer.
Attach the installation brackets using the screws provided.
■ ■
IMPORTANT: The front edges of the brackets must be level and
aligned to each other.
If using extension brackets, attach an installation bracket to the underside of each extension
■ ■
bracket using the provided screws and speed nuts.
If using spacer blocks, first attach the installation bracket to the
■ ■
spacer blocks or shims together.
Insert the legs of the installation bracket into the tabs on the spacer block.
➤ ■
Then rotate the installation bracket back.
➤ ■
Use a maximum of three spacer blocks (1
➤ ■
INSTALLATION
INSTALLATION
⁄ " floor clearance is recommended.
1
2
⁄ " is required to mount the brackets.
1
4
⁄ " drill bit.
3
32
⁄ ") per installation bracket.
1
2
⁄ " spacer block before stacking additional
1
2
4
Top of
Bracket
Ordered
Shade
Height
Floor Clearance
Tab
