Vertical Cellular Shade Side Stack Installation Instructions
Product View ................................................................................................................................................................. 1
Tools and Fasteners Needed ........................................................................................................................................ 2
Installation Overview .................................................................................................................................................... 2
Outside Mount Installation .......................................................................................................................................... 3
Inside/Ceiling Mount ................................................................................................................................................... 12
Valance Attachment ................................................................................................................................................... 19
OPERATION
Operating the Shade ................................................................................................................................................... 22
Troubleshooting .......................................................................................................................................................... 22
Removing the Shade, If Necessary ............................................................................................................................ 23
Cleaning Procedures ................................................................................................................................................... 23
.................................................................................................................................................................. 25
Cellular Shade Collection
Rev. A
9/3/19
Advertisement
Table of Contents
Related Manuals for Kirsch Cellular Shade Collection
Summary of Contents for Kirsch Cellular Shade Collection
-
Page 1: Table Of Contents
Cellular Shade Collection Vertical Cellular Shade Side Stack Installation Instructions GETTING STARTED Product View ................................. 1 Tools and Fasteners Needed ............................2 INSTALLATION Installation Overview ..............................2 Outside Mount Installation ............................3 Inside/Ceiling Mount ..............................12 Valance Attachment ..............................19 OPERATION Operating the Shade .............................. -
Page 2: Getting Started
GETTING STARTED Product View Installation Brackets Plate Headrail Moving Cord Rail Tensioners* Bracket* Tension Cord Fabric Carriers End Plate Stationary Rail Bracket Handle Stationary Rail Moving Rail Optional Outside Mount Hardware: Extension Bracket Inside Mount " Shim " Spacer Adaptor Block Stationary Rail *Located inside headrail... -
Page 3: Tools And Fasteners Needed
® Thank you for purchasing the Kirsch Cellular Shade Collection. With proper installation, operation, and care, your new shades will provide years of beauty and performance. To get started, unpack the shade and remove all foam/packaging materials. Check that all parts shown on the packing list are included with the order. -
Page 4: Outside Mount Installation
INSTALLATION INSTALLATION Stacking Design Determine which vertical cellular stacking design you are installing: left ■ ■ stack or right stack. If a sliding glass door opens from the right side, a left stack design is best. If ■ ■ the door opens from the left side, a right stack design is best. Right Stack Le Stack Valance Types... - Page 5 INSTALLATION INSTALLATION Determine where to place the top of the installation brackets. ■ ■ Top of Bracket Add the desired floor clearance to the ordered height of the shade. The ordered height can ➤ ■ be found on the packaging label. A minimum of ⁄...
- Page 6 INSTALLATION INSTALLATION Attach the spacer blocks and installation brackets with #6 hex head mounting screws long ■ ■ Maximum enough for a secure installation. (See chart below.) Longer screws are not provided. " Longer Screw The top of the spacer blocks should be at the desired shade height. ➤...
- Page 7 INSTALLATION INSTALLATION Prepare the Fabric Stack At the top of the fabric stack, a stationary rail bracket will be installed into the stationary rail and the moving rail bracket will be installed into the moving rail. In addition, a stationary rail bottom bracket will be installed into the bottom of the stationary rail. Insert the stationary rail bracket into the vertical rail on the side where the fabric stacks.
- Page 8 INSTALLATION INSTALLATION Insert the stationary rail bottom bracket into the bottom of the stationary rail. ■ ■ The bracket fits into grooves at the bottom of the rail. ➤ ■ Insert the bracket with the mounting flanges to the back, away from the fabric stack as shown in the photos. Do not seat ➤...
- Page 9 INSTALLATION INSTALLATION Slide the moving rail bracket and fabric carriers far enough into the headrail to hook the stationary rail bracket in place ■ ■ Tilt the bottom of the stationary rail toward you and hook the bracket to the headrail as illustrated. ➤...
- Page 10 INSTALLATION INSTALLATION Secure the stationary rail bracket using the provided small screw. Hold the bracket in ■ ■ place and screw through either of the two holes on the bracket. NOTE: Two #8 x ⁄ " pan head screws are provided; one is a spare. Position the Cords and Set Cord Tension Unwrap the cord from the orange cord organizer.
- Page 11 INSTALLATION INSTALLATION Position the cords. ■ ■ From the outside of the end plate, place the washer on the end of one cord into the first slot from the rear on the inside of ➤ ■ the end plate, as shown. Loop the cord behind the end plate back through the second slot from the front and pull it taut to seat the washer.
- Page 12 INSTALLATION INSTALLATION Adjust the moving rail to vertical, if necessary. Work from the front side of the shade. ■ ■ Locate the Phillips screws on the moving rail bracket. ➤ ■ To adjust the bottom end of the moving rail to the right, loosen the right screw one-half turn, then tighten the left screw ➤...
-
Page 13: Inside/Ceiling Mount
INSTALLATION INSTALLATION Inside/Ceiling Mount Mount the Installation Brackets Mark 8" in from each jamb. This marks the ■ ■ center points of the two end brackets. 8" Space Evenly Space Evenly 8" Mark the locations of any additional ➤ ■ brackets, spaced evenly between the two Jamb Jamb... - Page 14 INSTALLATION INSTALLATION Prepare the Fabric Stack Insert the stationary rail bracket into the vertical rail on the side where the fabric stacks. ■ ■ The bracket fits into the grooves on the rear of the vertical rail. ➤ ■ Insert the bracket until it is seated and the bracket catch snaps into the hole on the back of the rail. Check that the bracket ➤...
- Page 15 INSTALLATION INSTALLATION Install the Rails and Fabric Stack into the Headrail Rear Grooves Insert the moving rail onto the moving rail bracket. ■ ■ The bracket fits into the grooves on the rear of the vertical rail. Be sure to fit the bracket ➤...
- Page 16 INSTALLATION INSTALLATION Hook the stationary rail bracket in place. ■ ■ Hook the stationary rail bracket to the headrail as illustrated. ➤ ■ Move the stationary rail flush against the jamb. ➤ ■ Stationary Rail Bracket You may allow the stationary rail to hang freely. ➤...
- Page 17 INSTALLATION INSTALLATION Secure the stationary rail bracket using the provided small screw. Hold the bracket in ■ ■ place and screw through either of the two holes on the bracket. NOTE: Two #8 x ⁄ " pan head screws are provided; one is a spare. Position the Cords and Set Cord Tension Unwrap the cord from the orange cord organizer.
- Page 18 INSTALLATION INSTALLATION Position the cords. ■ ■ Place the washer on the end of one cord into the first slot from the rear on the inside of the end plate, as shown. Loop the ➤ ■ cord behind the end plate back through the second slot from the front and pull it taut to seat the washer Cut the washer from the end of the other cord and tie the cord to the cord tensioner using a square knot.
- Page 19 INSTALLATION INSTALLATION Adjust the moving rails to vertical, if necessary. Work from the front side of the shade. ■ ■ Locate the Phillips screws on the moving rail bracket. ➤ ■ To adjust the bottom end of the moving rail to the right, loosen the right screw one-half turn, then tighten the left screw ➤...
-
Page 20: Valance Attachment
INSTALLATION INSTALLATION Valance Attachment Attach Valance Clips Attach the valance clips to the headrail. ■ ■ Position the bottom of the valance clip under the ➤ ■ bottom lip of the headrail. Headrail Rotate the valance clip up to snap it into place on ➤... - Page 21 INSTALLATION INSTALLATION Attach the valance to the valance clips, as shown. ■ ■ nsert the top of the valance into the top of the ➤ ■ valance clip. Rotate the valance down to snap it into place ➤ ■ onto the headrail. Valance TIP: Tap the valance at each clip to assure that the valance is securely attached to the valance clips and the clips are securely attached to the headrail.
- Page 22 Valance INSTALLATION INSTALLATION Attach dovetail brackets to the valance clips. ■ ■ Insert the top of the dovetail bracket into the ➤ ■ top of the valance clip. Headrail Rotate the dovetail bracket down to snap it ➤ ■ in place. Dovetail Bracket Attach the valance to the dovetail brackets, as shown below.
-
Page 23: Operating The Shade
INSTALLATION INSTALLATION Operating the Shade Use the handle to traverse the shade to the desired position. ■ ■ A magnet in the moving rail will secure the shade in the fully closed position. ■ ■ Le Stack Right Stack Troubleshooting Problem The installation brackets do not allow enough clearance for the shade to clear moldings or door handle(s). -
Page 24: Care
“Install the Rails and Fabric Stack into the Headrail” on page 7 (OB) or page on page 14 (IB). Cleaning Procedures ® Kirsch Vertical Cellular Shades are made of anti-static, dust-resistant fabric which repels dirt and dust. For most cellular fabrics, the following cleaning options are available. - Page 25 INSTALLATION CARE Spot-Cleaning CAUTION: Do not spot-clean Harmony, Naturelle, Oceanside, and Sonora fabrics. Prepare a solution of warm water and a mild detergent. ■ ■ Dampen a clean cloth in the solution and wring it out. ■ ■ Dab the spot with the dampened cloth until it is removed. Do not rub the fabric. ■...
-
Page 26: Warranty
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. © 2019 Kirsch Custom Window Coverings. All rights reserved. All trademarks used herein are the property of Kirsch or their respective owners. 09/19...
