Roman Shades Collection
Product View ................................................................................................................................................................ 1
Tools and Fasteners Needed ....................................................................................................................................... 2
Installation Overview ................................................................................................................................................... 2
Mount the Installation Brackets - Inside Mount with Valance ............................................................................... 3
Mount the Installation Brackets - Inside Mount without Valance ......................................................................... 4
Mount the Installation Brackets - Outside Mount without Valance ...................................................................... 6
Mount the Installation Brackets - Outside Mount with Valance ............................................................................ 7
Install the Shade ........................................................................................................................................................... 9
Install the Shade into the Brackets ........................................................................................................................... 9
Attach the Valance Fabric (If Applicable) ............................................................................................................... 10
Connect the Power Source ....................................................................................................................................... 11
OPERATION
Testing the Shade ...................................................................................................................................................... 14
Using the Automation Remote ................................................................................................................................. 14
Resetting the Shade (If Necessary) .......................................................................................................................... 15
Troubleshooting ......................................................................................................................................................... 16
CARE
Removing the Shade (If Necessary) ......................................................................................................................... 18
Dressing Kirsch Roman Shades ............................................................................................................................... 18
Cleaning Procedures .................................................................................................................................................. 18
.................................................................................................................................................................. 19
Automation
Installation Instructions
Rev. A
9/3/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kirsch Roman Shades Automation
Summary of Contents for Kirsch Roman Shades Automation
-
Page 1: Table Of Contents
Using the Automation Remote ..........................14 Resetting the Shade (If Necessary) .......................... 15 Troubleshooting ................................. 16 CARE Removing the Shade (If Necessary) ......................... 18 Dressing Kirsch Roman Shades ..........................18 Cleaning Procedures ..............................18 WARRANTY .................................. 19 Rev. A 9/3/19... -
Page 2: Getting Started
GETTING STARTED Product View Installation Brackets Attached Battery Wand (Standard) DC Power Supply Satellite Battery Pack or DC Power Supply (Optional) -
Page 3: Tools And Fasteners Needed
GETTING STARTED ® Thank you for purchasing the Kirsch Roman Shades with Automation Collection. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 4: Mount The Installation Brackets - Inside Mount With Valance
INSTALLATION INSTALLATION Mount the Installation Brackets — Inside Mount with Valance With the optional valance, first the valance headboard is mounted inside the casement and then the installation brackets are mounted to the valance headboard. Locate the valance headboard inside the window casement. Position the headboard against the head jamb. ■... -
Page 5: Mount The Installation Brackets - Inside Mount Without Valance
INSTALLATION INSTALLATION Mount the Installation Brackets — Inside Mount without Valance Mark 2” in from each jamb. ■ If more than two installation brackets came with your order, space additional bracket(s) evenly between the two end ➤ brackets and mark their location. Mount into wood whenever possible. With shades using a battery wand, there must be a minimum of 15½”... - Page 6 INSTALLATION INSTALLATION With Attached Battery Wand " Needed for Rear Clearance 1½" Minimum Inside Mount " Fully Recessed Mount Window Casement Window Casement Bracket Bracket Battery Wand Battery Wand " " " Satellite Battery Pack or DC Power Supply " Min Inside Mount 2½"...
-
Page 7: Mount The Installation Brackets - Outside Mount Without Valance
INSTALLATION INSTALLATION Drill the screw holes using a ” drill bit. ■ Attach the installation brackets using the screws provided. ■ Check that the mounting surface is level and the brackets are aligned. If mounting to a heavily textured surface, shim the ➤... -
Page 8: Mount The Installation Brackets - Outside Mount With Valance
INSTALLATION INSTALLATION Mount the Installation Brackets — Outside Mount with Valance With the optional valance, first the valance headboard is mounted and then the installation brackets are mounted to the wall or molding under the headboard. The standard shade has an attached battery wand requiring a spacer block to be used with the installation bracket. DC power supply or satellite battery pack will not require a spacer block. - Page 9 INSTALLATION INSTALLATION Mount the shade installation brackets to the wall or molding underneath the valance headboard. ■ The top of the installation brackets must be ¼” below the bottom of the ➤ valance headboard, so that the L-brackets do not interfere with shade installation.
-
Page 10: Install The Shade
INSTALLATION INSTALLATION Install the Shade Battery Wand Clip If You Have a Battery Wand Clip... (For DC power supply or satellite battery pack installations, skip this step.) Attach the battery wand clip to the headrail. ■ IMPORTANT: Position the clip so that the battery wand will be between installation brackets. -
Page 11: Attach The Valance Fabric (If Applicable)
INSTALLATION INSTALLATION Attach the Valance Fabric (If Applicable) Center the valance fabric in front of the valance headboard. Press the strip of hook-and-loop material on the fabric to the ■ hook-and-loop material on the front of the headboard. Be sure the top of the valance fabric is aligned and level with the top of the valance headboard. ➤... -
Page 12: Connect The Power Source
Install the batteries according to the instructions on the battery wand label. ■ Squeeze Latch NOTE: Kirsch recommends AA alkaline batteries for use with our battery-powered shades. These will provide approximately one year of operation, depending on usage. Lithium and rechargeable batteries are not recommended. Replace the cap. - Page 13 INSTALLATION INSTALLATION If You Have a Satellite Battery Pack... Wall Mount Bracket Install Batteries into the Battery Wand See the instructions on the previous page. ■ Mount the Satellite Battery Pack Decide where you want to attach the wall mount bracket. A satellite battery pack may be mounted in any orientation. ■...
- Page 14 INSTALLATION INSTALLATION If You Have a Y-Connector for Adapting Two Battery Wands... Install the Batteries into the Battery Wand or Satellite Battery Pack Refer to “Install Batteries into the Battery Wand” — Page 11. ■ Mount the Battery Wand or Satellite Battery Pack Refer to “Mount the Battery Wand into the Battery Wand Clip”...
-
Page 15: Testing The Shade
INSTALLATION CARE Testing the Shade Testing the shade with the manual control button will allow you to ensure that the motor and power source are working correctly. CAUTION: When raising the shade for the first time, observe how the fabric stacks. It should stack evenly. Immediately stop the shade if the bottom rail is not level or the shade starts to rub against either window jamb. -
Page 16: Resetting The Shade (If Necessary)
INSTALLATION OPERATION Further Operation and Programming Information Automation Remote For information regarding operation and programming of the Automation remote, refer to your Automation Remote Control Guide. Resetting the Shade (If Necessary) Basic Reset The basic reset is used to reset the shade’s travel limits. This procedure will also reset the ♥ FAVORITE position to its default (shade closed halfway). -
Page 17: Troubleshooting
First review the guide that came with your control device. ■ Refer to the following troubleshooting procedures below for the specific solutions for your shade. ■ If questions remain, please contact the Kirsch® Consumer Support at 1-844-KIRSCH2 (844-547-7242). Problem The shade will not fit into the installation brackets. Solution If the shading has a battery wand, check that the wand is not interfering with the installation brackets. - Page 18 INSTALLATION OPERATION Problem Shade is too short. Solution If the shade was ordered with a valance, be sure the valance and shade brackets are installed properly. The valance headboard is considered in the overall height of the shade and valance combined. A deduction in shade height is taken by fabrication to accommodate the thickness of the valance headboard.
-
Page 19: Removing The Shade (If Necessary)
Finger or Flat Blade Screwdriver Dressing Kirsch Roman Shades NOTE: As with all textiles, the fabric on your Roman shade(s) is subject to some inherent variations. Slight dye-lot variations, puckering or wrinkling are within textile industry standards and should be considered normal. -
Page 20: Warranty
© 2019 Kirsch Custom Window Coverings. All rights reserved. All trademarks used herein are the property of Kirsch or their respective owners. 09/19...
