Extreme Flight TURBO RAVEN EXP Assembly Manual page 4

Tips for Success:
1. Before starting assembly, take a few minutes to read the entire instruction manual to
familiarize yourself with the assembly process.
2. Please take a few minutes and go over all the seams on the aircraft with a covering iron
on a medium heat setting.
3. Apply a couple drops of CA to high stress areas such as anti-rotation pins, landing gear
mounts, servo trays and motor box joints .
4. When applying decals, first clean the area where the decal will be applied with alcohol.
Mist the area lightly with Windex or Rapid Tack before applying the decal which will
allow you to properly position it, then use a rubber squeegee to push all of the liquid from
under the decal. This will result in very few air pockets trapped under the decal.
5. Take the time to properly balance and trim your aircraft and set up rates and
exponential values. Your flying experience will be greatly enhanced by doing this.
The Ultracote colors used on the Turbo Raven are as follows:
True Red #HANU866, Pearl Dark Yellow #HANU843, Midnight Blue #HANU885, White
#HANU870 and Transparent Blue #HANU954
