Power Switch; Liquid Crystal Display; Indicator Lights; Reset Mechanism - Taylor PH61 Operator's Manual

Power Switch

The power switch is located under the control panel
on the left hand side of the unit. When placed in the
ON position, the power switch allows softech panel
operation.

Liquid Crystal Display

The Liquid Crystal Display (LCD) is located on the
front control panel. The LCD is used to show in what
mode the unit is operating and whether or not there
is sufficient mix.

Indicator Lights

MIX LOW - When the MIX LOW light begins to
flash, it indicates the mix hopper has a low supply of
mix and should be refilled as soon as possible. The
word "LOW" will also display on the LCD indicator
next to the word "MIX".
MIX OUT - When the MIX OUT light begins to flash,
it indicates the mix hopper has been almost
completely exhausted and has an insufficient supply
of mix to operate the unit. The word "OUT" will also
display on the LCD indicator next to the word "MIX".
At this time, the AUTO mode is locked out and the
unit will be placed in the STANDBY mode. To initiate
the refrigeration system, add mix to the mix hopper
and press the AUTO key. The unit will automatically
begin operation.
HEAT MODE - When the HEAT MODE light is
flashing, it indicates that the unit is in the process of
a heat cycle.
CLEAN MANUALLY - When the CLEAN
MANUALLY light is flashing, it indicates that the
machine must be disassembled and brush cleaned
within 24 hours.
When all four indicator lights are flashing, this
signifies a locked condition. Once a hard lock
condition has been remedied, two lights will remain
flashing until the mix low and mix out conditions
have been satisfied. During a soft lock condition, all
four lights will stop flashing once the unit has been
placed in a heat cycle.
PH61 Peristaltic Pump

Reset Mechanism

The reset button is located in the right side panel.
The reset mechanism protects the beater motor
from an overload condition. Should an overload
occur, the reset mechanism will trip. To properly
reset the unit, place the power switch in the OFF
position. Press the reset button firmly. Turn the
power switch to the ON position. Clear the fault.
Press the WASH key and observe the unit's
performance. Open the side access panel to check if
the beater motor is turning the drive shaft in a
clockwise (from the operator end) direction without
binding.
Note: Do not use metal objects to press
the reset button. Failure to follow this instruction
may result in serious electrical shock.
If the beater motor is turning properly, press the
WASH key to cancel the cycle. Press the AUTO key
to resume normal operation. If the unit shuts down
again, contact a service technician.
17
