An equipotential grounding lug is provided with
this unit. Some countries require the grounding lug
be properly attached to the rear of the frame by the
authorized installer. The installation location is
marked by the equipotential bonding symbol (5021
of IEC 60417-1) on both the removable panel and
the unit's frame.
DO NOT use a water jet to clean or rinse
the unit. Failure to follow these instructions may
result in serious electrical shock.
S
DO NOT allow untrained personnel to
operate this unit.
S
DO NOT operate the unit unless all service
panels and access doors are restrained with
screws.
S
DO NOT remove any internal operating
parts (including, but not limited to, freezer
door, beater, or scraper blades), unless all
control switches are in the OFF position.
Failure to follow these instructions may result in
severe personal injury, especially to fingers or
hands, from hazardous moving parts.
This unit has many sharp edges that can
cause severe injuries.
S
DO NOT put objects or fingers in the door
spout. This may contaminate the product
and cause severe personal injury from blade
contact.
S
USE EXTREME CAUTION when removing
the beater assembly. The scraper blades
are very sharp.
This unit must be placed on a level surface.
Extreme care should be taken when moving the unit
for any reason. Two or more persons are required to
safely move this unit. Failure to comply may result in
personal injury or damage to the unit.
Access to the service area of the unit must
be restricted to persons having knowledge and
PH61 Peristaltic Pump
practical experience with the unit, in particular as far
as safety and hygiene are concerned.
Cleaning and sanitizing schedules are
governed by your state or local regulatory agencies
and must be followed accordingly. Please refer to
the cleaning section of this Operator Manual for the
proper procedure to clean this unit.
This unit is designed to maintain product
temperature under 41_F (5_C). Any product being
added to this unit must be below 41_F (5_C). Failure
to follow this instruction may result in health hazards
and poor freezer performance.
DO NOT draw product during the HEAT
cycle because of high product temperatures.
WARNING!
Some consumers are highly allergic to
strawberries. In some severe cases,
strawberry allergic reactions can cause
death. When serving shakes, make sure
the draw handle is closed automatically by
the portion control device and that the
white spot is visible.
DO NOT obstruct air intake and discharge openings:
6" (152 mm) minimum air space on all sides. Failure
to follow this instruction may cause poor freezer
performance and damage to the unit.
For Indoor Use Only: This unit is designed to
operate indoors, under normal ambient
temperatures of 70_-75_F (21_-24_C). The unit has
successfully performed in high ambient
temperatures of up to 104_F (40_C) at reduced
capacities.
DO NOT run the unit without product. Failure to
follow this instruction can result in damage to the
unit.
NOISE LEVEL: Airborne noise emission does not
exceed 78 dB(A) when measured at a distance of
1.0 meter from the surface of the unit and at a
height of 1.6 meters from the floor.
7
Safety
