Model 750, 751, 754, 774,
791, & 794 Soft Serve Freezers
Original Operating Instructions
028754- M
OPERATOR'S
MANUAL
2/01/02 (Original Publication)
Updated 12/22/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 750 and is the answer not in the manual?

Questions and answers

Related Manuals for Taylor 750

Summary of Contents for Taylor 750

  • Page 1 OPERATOR'S MANUAL Model 750, 751, 754, 774, 791, & 794 Soft Serve Freezers Original Operating Instructions 028754- M 2/01/02 (Original Publication) Updated 12/22/15...
  • Page 2 Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties. All rights reserved. Taylor Company a division of Carrier Commercial Refrigeration, Inc. 750 N. Blackhawk Blvd. Rockton, IL 61072...

  • Page 3: Table Of Contents

    ............Models 750 & 751 Single Spout Door and Beater Assembly .
  • Page 4 Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties. All rights reserved. Taylor Company a division of Carrier Commercial Refrigeration, Inc. 750 N. Blackhawk Blvd. Rockton, IL 61072 Table of Contents Models 750, 751, 754, 774, 791, 794...

  • Page 5: To The Installer

    This piece of equipment is made in the USA and has This unit has many sharp edges that can USA sizes of hardware. All metric conversions are cause severe injuries. approximate and vary in size. 131206 Models 750, 751, 754, 774, 791, 794 To the Installer...
  • Page 6 GFI, to protect FOLLOW YOUR LOCAL ELECTRICAL CODES! against the leakage of current, installed by the authorized personnel to the local codes. 101027 To the Installer Models 750, 751, 754, 774, 791, 794...
  • Page 7 NEVER If the supply cord is damaged, it must be replaced by fill any refrigerant cylinder completely with liquid. an authorized Taylor service technician in order to Filling the cylinder to approximately 80% will allow for avoid a hazard.

  • Page 8: To The Operator

    It is the unit owner’s responsibility to make this fact known to any technician he employs. Note: Your Taylor warranty is valid only if the parts are authorized Taylor parts, purchased from the local It should also be noted that Taylor does not warrant the authorized Taylor Distributor, and only if all required refrigerant used in its equipment.

  • Page 9: Safety

    We, at Taylor Company, are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built−in DO NOT operate the freezer unless it is safety features to protect both you and the service properly grounded.
  • Page 10 This freezer must be placed on a level surface. Failure to comply may result in personal injury meter from the surface of the machine and at a height or equipment damage. of 1.6 meters from the floor. 130819 Safety Models 750, 751, 754, 774, 791, 794...

  • Page 11: Operator Parts Identification

    Panel−Upper Side Right 042317 Panel A.−Front X50754 Pan−Drip 050766 O−Ring−.643 OD x .077 W 018572 Panel−Right Side 050742 O−Ring−3/8 OD x .070 W 016137 Shield−Splash 022763 Orifice 022465−100 Tray−Drip 013690 101217 Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 12: Model 751

    Panel A.−Lower Side Right X24424−SER Louver−Side−Top 051191 Shield−Splash 022763 Panel A.−Front X33237 Tray−Drip 14−7/8 x 5−1/8 013690 Adaptor A.−Caster X18915 Panel−Upper Side 024426 Caster−4” Swivel 5/8” Stem 034081 w/Brake Panel−Service 047170 111101 Operator Parts Identification Models 750, 751, 754, 774, 791, 794...

  • Page 13: Model 754

    Panel A.−Side Lower Right X46448−SER O−Ring−3/8 OD x .070 W 016137 Panel−Service 046584 Orifice 022465−100 Shield−Splash 022766 Pan−Drip 17−1/4” Long 027504 Tray−Drip 014533 Panel A.−Front X32956 Caster−Swivel 018794 Adaptor A.−Caster X18915 Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 14: Model 774

    016137 Caster−4” Swivel 5/8 Stem/Brake 034081 Orifice 022465−100 Panel−Upper Side Left 028822 Panel A.−Front−Syrup Inactive X42539 Pan−Drip 17−1/4” Long 027504 Adaptor A.−Caster X18915 Lid with Ladle 1 oz. 036575 140616 Operator Parts Identification Models 750, 751, 754, 774, 791, 794...

  • Page 15: Model 774 Topping Pump (053794−)

    O-Ring-1 OD x .103 W 048148 Kit-Valve-Captured Ball Shallow 048166-001 Includes: 1 - Body A.-Pump Valve 1 - O-Ring-1-5/16 OD x .103W (048149) 1 - Brush-cleaning (054068) 1 - Instruction Sheet-Installation/Cleaning Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 16: Model 791

    STUD−NOSE CONE 068410 CASTER−4” SWV 5/8 STEM 034081 W/BRAKE PANEL−SIDE 069038 TRAY−DRIP 16−7/8L X 5−1/8 020157 KIT A.−COVER−HOPPER X68150 SHIELD−SPLASH 022765 TUBE A.−FEED−SS−5/32 X29429−2 PAN−DRIP 19−1/2 LONG 035034 PANEL−REAR 041855 120613 Operator Parts Identification Models 750, 751, 754, 774, 791, 794...

  • Page 17: Model 794

    STUD−NOSE CONE 022822 PANEL−SIDE *LEFT 068691 O−RING−3/8 OD X .070W 016137 PANEL−SIDE *RIGHT 068692 O−RING−.643 OD X .077W 018572 PANEL−SERVICE 064000 ORIFICE 022465−100 SHIELD−SPLASH 022765 PANEL A.−FRONT X41820−SP3 TRAY−DRIP 021057 130508 Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 18: Models 750 & 751 Single Spout Door And Beater Assembly

    Models 750 & 751 Single Spout Door and Beater Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. HANDLE A.−DRAW NONADJ X69016 PLUG−PRIME 028805 DRAW HANDLE 028804 O−RING−PRIME PLUG 016137 SCREW−ADJUSTMENT 069014 PIN A.− PIVOT X22820 O−RING 1/4OD X .070W 015872 GASKET−DOOR HT 4”...

  • Page 19: Models 754, 774 & 794 Three Spout Door And Beater Assembly

    BEATER A.−3.4QT−HELICORE X31761 O−RING−3/8 OD X .070W 016137 BLADE−SCRAPER−PLASTIC 035174 HANDLE A.−DRAW *WHITE X81010−SP SHAFT−BEATER 032564 HANDLE−DRAW−WHITE 056248−1 SEAL−DRIVE SHAFT 032560 SCREW−ADJ.−5/16−24 056332 O−RING−1/4 OD X .070W 50 015872 151217 Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 20: Model 791 Three Spout Door And Beater Assembly

    VALVE A.- DRAW X69539 BLADE- SCRAPER 035174 O- RING- 7/8 OD X .103W- SIL 083693 SHAFT- BEATER 032564 CAP- DESIGN 014218 SEAL- DRIVE SHAFT 032560 DECAL- DOOR- 3 SPOUT 021521 151222 Operator Parts Identification Models 750, 751, 754, 774, 791, 794...

  • Page 21: Accessories

    **Note: A sample container of sanitizer is sent with the Sanitizer−Stera Sheen Green See note unit. For reorders, order Stera Sheen part no. 055492 (100 2 oz. packs) or Kay−5 part no. 041082 (200 packs). 140718 Models 750, 751, 754, 774, 791, 794 Operator Parts Identification...

  • Page 22: Important: To The Operator

    AUTO KEY been replaced with symbols to indicate their functions. POWER ON/OFF (TOGGLE) Your Taylor equipment is designed with these RESET BUTTON International symbols. Important: To the Operator Models 750, 751, 754, 774, 791, 794...

  • Page 23: Power Switch

    To cancel any function, press the key again. works with the SHR to maintain a good quality product. The light and mode of operation will shut off. 130819 Models 750, 751, 754, 774, 791, 794 Important: To the Operator...

  • Page 24: Reset Button

    (the end with the hole) and Note: Once the draw rate is set, tighten the lock nut place it into the mix inlet hole. Every time the with a wrench. 130819 Important: To the Operator Models 750, 751, 754, 774, 791, 794...

  • Page 25: Operating Procedures

    Pump the solution through the assembly to thor- cylinder. They all have 3.4 quart (3.2 liter) capacity oughly sanitize the pump. freezing cylinders. The Models 750, 751, 754, and 774 have 20 quart (18.9 liter) mix hoppers. The Models 791 Step 4 and 794 have 14 quart (13.2 liter) mix hoppers.
  • Page 26 Looking into the freezing cylinder, align the hole at the rear of the beater with the flats on the end of the drive shaft. Figure 9 Operating Procedures Models 750, 751, 754, 774, 791, 794...
  • Page 27 Slide the two o−rings into the grooves on the prime cylinder. With the door seated on the freezer studs, plug(s). Apply an even coat of Taylor Lube to the install the handscrews. Tighten equally in a crisscross o−rings and shaft(s).
  • Page 28 Note: These units feature adjustable draw handles to provide the best portion control. The draw handles can be adjusted for different flow rates. See page 20 for Figure 15 more information on adjusting these handles. 101109 Operating Procedures Models 750, 751, 754, 774, 791, 794...
  • Page 29 If the hole in the air orifice should become clogged, use soap and hot water to clear the Figure 20 hole. Do not enlarge the hole in the air orifice. Models 750, 751, 754, 774, 791, 794 Operating Procedures...

  • Page 30: Sanitizing

    [7.6 liters] of Stera−SheenR). USE WARM WA- TER AND FOLLOW THE MANUFACTURER’S SPECIFICATIONS. Step 2 Pour the sanitizing solution into the hopper and allow it to flow into the freezing cylinder. Figure 26 130118 Operating Procedures Models 750, 751, 754, 774, 791, 794...
  • Page 31 WASH key, cancelling the beater motor operation. Note: You have just sanitized the freezer. Be sure your hands are sanitized before continuing these Figure 29 instructions. Models 750, 751, 754, 774, 791, 794 Operating Procedures...

  • Page 32: Priming

    Fill the hopper with mix. As the mix level comes in contact with the mix level sensing probe on the rear Figure 33 wall of the hopper, the MIX LOW light will shut off. Operating Procedures Models 750, 751, 754, 774, 791, 794...

  • Page 33: Closing Procedure

    Models 754, 774, 791, and 794. solution in the freezing cylinder to agitate. Step 5 ALWAYS FOLLOW LOCAL HEALTH CODES. Place an empty pail beneath the door spout and raise the prime plug. 140718 Models 750, 751, 754, 774, 791, 794 Operating Procedures...

  • Page 34: Disassembly

    NSF. Step 4 ALWAYS FOLLOW LOCAL HEALTH CODES. Remove the o- rings from the air tube(s) and air orifice(s). 151124 Operating Procedures Models 750, 751, 754, 774, 791, 794...
  • Page 35 Step 8 Wipe clean all exterior surfaces of the freezer. Figure 36 Step 6 Remove the rear drip pan(s) and take to the sink for cleaning. Models 750, 751, 754, 774, 791, 794 Operating Procedures...

  • Page 36: Important: Operator Checklist

    5. Follow all lubricating procedures as outlined in freezing cylinder. Be sure to have a generous amount of cleaning solution on the brush. “Assembly”. 061122 Important: Operator Checklist Models 750, 751, 754, 774, 791, 794...

  • Page 37: Winter Storage

    7. If your machine is equipped with an auxiliary refrigeration system, check the auxiliary Your local Taylor Distributor can perform this winter condenser for accumulation of dirt and lint. Dirty storage service for you. condensers will reduce the refrigeration Wrap detachable parts of the freezer such as beater, capacity of the mix hopper.

  • Page 38: Troubleshooting Guide

    −−− 4. The mix in the mix hopper a. The temperature is out of a. Call service technician to adjust the mix hopper is too cold. adjustment. temperature. Troubleshooting Guide Models 750, 751, 754, 774, 791, 794...
  • Page 39 The circuit breaker is off b. Turn the breaker on, or replace the fuse. or the fuse is blown. c. The beater motor is out on c. Reset the freezer. reset. Models 750, 751, 754, 774, 791, 794 Troubleshooting Guide...
  • Page 40 Install the air tube in the mix inlet hole, using the incorrectly. end with the small hole in the side. d. The air orifice is not d. Install the air orifice in the air tube. installed. Troubleshooting Guide Models 750, 751, 754, 774, 791, 794...

  • Page 41: Parts Replacement Schedule

    White Bristle Brush, 1” x 2” Inspect & Replace Minimum if Necessary Black Bristle Brush, 1” x 2” Inspect & Replace Minimum if Necessary Double−Ended Brush Inspect & Replace Minimum if Necessary Models 750, 751, 754, 774, 791, 794 Parts Replacement Schedule...

  • Page 42: Limited Warranty On Equipment

    Taylor, through an authorized Taylor distributor or service agency, will provide a new or re−manufactured part, at Taylor’s option, to replace the failed defective part at no charge for the part. Except as otherwise stated herein, these are Taylor’s exclusive obligations under this limited warranty for a Product failure.
  • Page 43 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.

  • Page 44: Limited Warranty On Parts

    Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or re−manufactured Part, at Taylor’s option, to replace the failed defective Part at no...
  • Page 45 Parts or the units in which they are installed repaired or altered in any way so as, in the judgment of Taylor, to adversely affect performance, or normal wear or deterioration.

  • Page 46: Taylor Company

    LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.

This manual is also suitable for:

751754791774794
