Components - Wall Mounted - Inta HTMWMCP Installation And Maintenance Instructions Manual

Components
15
5
12
Item Description
1 Body inc. Outlet Diffuser
2 Thermostatic Cartridge
3 Lever
4 Lever Retaining Screw
5 Concealing Plate
6 Cold Water Inlet Tail Assembly
7 Hot Water Inlet Tail Assembly
8 Sealing Washer
9 Swivel Nut
© Intatec Ltd 2016
Wall Mounted with Fixed Spout
15
5
7
8
9
10
4
6
1
13
Item
10
11
12
13
14
15
3
3
2
14
Description
Hot Water Insulator
Cold Water Inlet Assembly
including 5 l/m flow regulator
Hot Water Inlet Assembly
including 5 l/m flow regulator
Hot Water Port Blanking Assembly
Cold Water Port Blanking Assembly
Backnut
11
