UM2222 Functional description of STM32H743I-EVAL, STM32H747I-EVAL and STM32H747I-DIS-
8.2

TouchGFX demonstration

Overview

The TouchGFX demonstration is available in binary format.
To show the TouchGFX demonstration, the user needs to load the full binary file available
under Demonstration/binaries
- STM32CubeDemo_STM32H743-Eval_VX.Y.Z_FULL.hex.
8.2.1

Audio player module

Overview
The audio player module provides a complete audio solution based on the STM32H7 Series
and delivers a high-quality music experience. It supports playing music in WAV format but
may be extended to support other compressed formats such as MP3 and WMA audio
formats. In the audio module, the user can select which song to play, whether by selecting it
from the playlist consisting of all the songs on the device, or by going through the directories
where the songs are. The audio player also consists of an equalizer that enables the user to
adjust the sound.

Figure 39. TouchGFX demonstration

Figure 40. TouchGFX - Audio player module
