ST FP-SNS-6LPNODE1 Quick Start Manual

ST FP-SNS-6LPNODE1 Quick Start Manual

Function pack for iot sensor node connection to 6lowpan networks through sub-1ghz rf communication
Hide thumbs

Advertisement

Quick Links

Download this manual
Quick Start Guide
STM32Cube Function Pack for IoT sensor node connection to
6LoWPAN networks through sub-1GHz RF communication
(FP-SNS-6LPNODE1)
Version 1.4 (April.10, 2019)

Advertisement

loading
Need help?

Need help?

Do you have a question about the FP-SNS-6LPNODE1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ST FP-SNS-6LPNODE1

Summary of Contents for ST FP-SNS-6LPNODE1

  • Page 1 Quick Start Guide STM32Cube Function Pack for IoT sensor node connection to 6LoWPAN networks through sub-1GHz RF communication (FP-SNS-6LPNODE1) Version 1.4 (April.10, 2019)
  • Page 2 Quick Start Guide Contents FP-SNS-6LPNODE1: STM32Cube Function Pack for IoT sensor node connection to 6LoWPAN networks through sub-1GHz RF communication Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...

  • Page 3: Hardware Overview

    S2-LP radio and operates in the 868 MHz ISM frequency band • The expansion board is compatible with ST morpho and Arduino UNO R3 connectors. The X-NUCLEO- S2868A1 interfaces with the STM32 Nucleo microcontroller via SPI connections and GPIO pins.
  • Page 4 SPSGRF-868 or EEPROM 64 Kbit SPI bus EEPROM with high-speed clock SPSGRF-915 (*) (*) Identification of the operating frequency of the X-NUCLEO- IDS01Ax (x=4 or 5) is performed through two resistors (R14 and R15). Latest info available at www.st.com X-NUCLEO-IDS01A4 X-NUCLEO-IDS01A5...
  • Page 5 The X-NUCLEO-IKS01A1 is a motion MEMS and environmental sensor evaluation board system. • It is compatible with the Arduino UNO R3 connector layout, and is designed around ST’s latest sensors. Key Features • The X-NUCLEO-IKS01A1 is a motion MEMS and environmental sensor evaluation board system.
  • Page 6 The X-NUCLEO-IKS01A2 is a motion MEMS and environmental sensor evaluation board system. • It is compatible with the Arduino UNO R3 connector layout, and is designed around ST’s latest sensors. Key products on board LSM6DSL MEMS 3D accelerometer (±2/±4/±8/±16 g) + 3D gyroscope (±125/±245/±500/±1000/±2000 dps)
  • Page 7 X-NUCLEO-6180XA1 Hardware Description • The X-NUCLEO-6180XA1 is proximity and ambient light sensor evaluation and development board system, designed around VL6180X, a device based on ST’s FlightSense , Time-of- Flight technology. • The VL6180X communicates with STM32 Nucleo developer board host microcontroller through an I2C link available on the Arduino UNO R3 connector.

  • Page 8: Software Overview

    FP-SNS-6LPNODE1 FP-SNS-6LPNODE1 Software Description FP-SNS-6LPNODE1 is an STM32Cube Function Pack. Thanks to Software Overview this package you can connect your IoT node to a 6LoWPAN Wireless Sensors Network and expose the sensors and actuator resources using standard application layer protocols. This software...
  • Page 9 Quick Start Guide Contents FP-SNS-6LPNODE1: STM32Cube Function Pack for IoT sensor node connection to 6LoWPAN networks through sub-1GHz RF communication Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
  • Page 10 1x PC with Windows 7, 8 or 10 • 1x USB type A to Mini-B USB cable Mini USB • The FP-SNS-6LPNODE1 package contains some sample applications for demonstration and evaluation X-NUCLEO-IDS01A4 purpose for three different wireless node configurations, X-NUCLEO-6180XA1...
  • Page 11 Setup & Demo Examples HW prerequisites (2/2 • Important Note If using X-NUCLEO-IKS01A1 and X-NUCLEO-S2868A1, to avoid a resource conflict, the 0 Ω resistor at position SB21 on the X- NUCLEO-IKS01A1 must be usage removed...
  • Page 12 Setup & Demo Examples SW prerequisites • STSW-LINK009: • ST-LINK/V2-1 USB driver • STSW-LINK007: • ST-LINK/V2-1 firmware upgrade • FP-SNS-6LPNODE1 • Copy the .zip file content into a folder on your PC • The package will contain source code example (Keil, IAR, System Workbench for STM32) based...
  • Page 13 Go to www.st.com/stm32ode-fp FP-SNS-6LPNODE1 package structure Select FP-SNS-6LPNODE1 HTML Docs BSP, HAL and Drivers 6LoWPAN stack Application examples Download & unpack FP-SNS-6LPNODE1 Download and install STM32 Nucleo ST-LINK/V2-1 USB driver Modify and build the application Open project example, e.g. “ipso-mems”...
  • Page 14 FP-SNS-6LPNODE1 System Overview – End-to-End Deployment Example Wireless Sensors Node (example) Hardware: NUCLEO-F410RE + X-NUCLEO- S2868A1 (sub-1 GHz) + X-NUCLEO-6180XA1 (Time of flight sensor) Software: FP-SNS-6LPNODE1 package, Application “ipso-flightsense” application Server REST Access to the (e.g. Leshan LWM2M) Wireless Nodes Resources...
  • Page 15 FP-SNS-6LPNODE1 6LoWPAN-to-Wi-Fi Bridge Setup 6LoWPAN to Wi-Fi bridge Setup 6LoWPAN-WiFi Bridge Go to www.st.com/stm32ode-fp FP-NET-6LPWIFI1 Package Wi-Fi AP/Router Select the FP-NET-6LPWIFI1 package Follow the installation instructions to configure and connect the bridge to a Wi-Fi AP/Router USB type A to Mini-B USB cable...
  • Page 16 FP-SNS-6LPNODE1 Wireless Sensors Node Setup (1/4) Go to www.st.com/stm32ode-fp Select the FP-SNS-6LPNODE1 package, download and extract the zip file Wireless Sensors Node Select one of the three supported wireless nodes hardware configuration, assemble the STM32 Nucleo and X-NUCLEO expansion boards, connect the...
  • Page 17 FP-SNS-6LPNODE1 Wireless Sensors Node Setup (2/4) Wait for the node (acting in this example as a LWM2M client) to complete the registration with the LWM2M server. If the client registration is successful, this will be notified by the node. Take note of the client ID...
  • Page 18 FP-SNS-6LPNODE1 Wireless Sensors Node Setup (3/4) Click on the corresponding Client Endpoint to visualize the client homepage on the Leshan server: the available resources hosted on the wireless sensor node are listed on the web page...
  • Page 19 FP-SNS-6LPNODE1 Wireless Sensors Node Setup (4/4) Click either on “Observe” or “Read” to access one or more resources on the node (for example the temperature sensor data). “Observe” is a feature that enables to get updates of sensor data when they change, while “Read”...
  • Page 20 FP-NET-6LPNODE1 Additional LWM2M Demo Setup Tips (1/2) • It is recommended - especially when using the public Leshan LWM2M server – to avoid using a host PC that is inside a network behind a proxy (which typically happens in corporate networks)  this proxy may create issues, in particular with the visualization of the notifications •...
  • Page 21 FP-NET-6LPNODE1 Additional LWM2M Demo Setup Tips (2/2) • The following table contains a list of actually observable resources • Note that observing other resources not listed here might have side effects due to the current LWM2M server implementation • Note that in case of observation some thresholds and timers apply. For example, don’t expect the presence sensor to react in less than one second, or a new temperature sensor reading to be sent every few seconds Object Object...
  • Page 22 DB3010: STM32Cube Function Pack for IoT sensor node connection to 6LoWPAN networks through sub-1GHz RF communication – Data brief • UM2100: Getting started with FP-SNS-6LPNODE1 software for IoT sensor node connection to 6LoWPAN networks using sub- 1GHz RF – User Manual •...
  • Page 23 • AN4663: VL6180X expansion boards - Description of version 1 and version 2 – Application note • UM1852: Proximity and ambient light sensor expansion board based on VL6180X for STM32 Nucleo – User manual Consult www.st.com for the complete list...
  • Page 24 Quick Start Guide Contents FP-SNS-6LPNODE1: STM32Cube Function Pack for IoT sensor node connection to 6LoWPAN networks through sub-1GHz RF communication Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
  • Page 25 The STM32 Open Development Environment (ODE) consists of a set of stackable boards and a modular open SW environment designed around the STM32 microcontroller family. STM32 Nucleo STM32Cube expansion boards development software (X-NUCLEO) STM32Cube STM32 Nucleo expansion software development boards (X-CUBE) Function Packs (FP) www.st.com/stm32ode...
  • Page 26 Power supply STM32 microcontroller through USB or external source Integrated debugging Complete product range and programming from ultra-low power to high-performance ST-LINK probe ST morpho extension header Arduino™ UNO R3 extension headers www.st.com/stm32nucleo...
  • Page 27 Boards with additional functionality that can be plugged directly on top of the STM32 Nucleo development board directly or stacked on another expansion board. Connect Power Move/Actuate Interact Sense Motion MEMS sensors Environmental sensors DIL24 support for new devices Example of STM32 expansion board (X-NUCLEO-IKS01A1) www.st.com/x-nucleo...

  • Page 28: Software Components

    Environment is compatible with a number of IDEs including IAR EWARM, Keil MDK, and GCC-based environments. Users can choose from three IDEs from leading vendors, which are free of charge and deployed in close cooperation with ST. These include Eclipse-based IDEs such as Ac6 System Workbench for STM32 and the MDK-ARM environment.
  • Page 29 NFC, Wi-Fi, GNSS Audio amplifier ACCESS Touch controller Translate Operation Amplifier CREATE Move / Stepper motor driver DC & BLDC motor driver Actuate Industrial input / output POWER Power Energy management & battery General-purpose microcontrollers PROCESS Process Secure microcontrollers www.st.com/stm32ode Software...
