7. Auxiliary Equipment Inactive
The ProLogic Relays are rated for 120/240VAC, 300W, 25A. To avoid damage, make
sure wired equipment does not exceed these specifications.
Inspect relay LED
Service mode
Step 7A
Step 7B
The ProLogic will only attempt to engage a relay if the
Activate service mode & press the relay button. IF the
specific Auxiliary LED is illuminated on the display.
LED illuminates, a control related feature is overriding
Press the Auxiliary button that corresponds with the
the relay, preventing normal operation from occurring
relay in question. IF the relay LED fails to turn ON, go to
(example: interlock...etc.), go to step 7C. IF LED does
step 7B. IF ON, jump to step 7D.
not turn ON, replace the local display
(see pg.
17).
40
