How To: Adjust Chlorinator Output
Follow these steps to adjust the Chlorinator Output Percentage ONLY if Salt
Chlorination is Enabled. NOTE: IF Sense & Dispense 'ORP Auto Sensing' is being used,
output must be adjusted under the 'Chemistry Config. Wizard'; refer to next page.
Step 1
To display the settings, press the 'MENU' key until
'Settings Menu' appears. Then press the (>) until 'Super
Chlorinate' appears .
Step 3
Use the (+) or (-) button to adjust desired chlorinator output. If
multiple bodies of water are programmed, press the (>) button
again. IF only one body of water, press the 'Menu' button to exit.
Note: If the chlorine levels do not increase within 24 hours, test the water chemistry to determine the
9
current salt, stabilizer, phosphate, and nitrate levels.
Step 2
Use the (+) or (-) button to toggle between super chlorinate 'On'
or 'Off' (depending on preference). Then press the (>) one time
to display chlorinator % options.
Step 4
For the second body of water, use the (+) or (-) key to adjust the
desired chlorinator output. Once complete, press the 'Menu'
button to exit.
