Table Of Contents - Hayward ProLogic Troubleshooting Manual

How ProLogic® Works & Main PCB Layout
How To:
Reset Config. to Default & Reset Average Salt
Adjust Chlorinator Output & Adjust ORP Set Point
Change Cell Type & Clear Inspect Cell Message
Clean the Turbo Cell
Troubleshooting:
ProLogic vs. AquaLogic SKUs
1. No Cell Power/Low Volts
2. Blank Display
3. CSM Comm Error
4. Chlorinator Off, High Salt/Amps
5. Comm Error 1 or 2
6. Heater Not Firing
7. Auxilariry Not Running
Additional Information:
Cell Compatibility Chart & Air Sensor Chart
Salt Addition Chart & Chlorine Output
Reading Serial Numbers
3

Table of Contents

Pg. 4-5
Pg. 6-15
7-8
9-10
11-12
13-15
Pg. 16-43
17
18-20
21-24
25-27
28-31
32-34
35-38
39-43
Pg. 44-50
45-46
47-49
50
