Hayward ProLogic Troubleshooting Manual page 30

4. Chlorinator OFF, High Salt/Amps (cont.)
The message 'Chlorinator Off – High Salt/Amps' indicates that the ProLogic has
detected an amperage draw, from the turbo cell, that exceeds the allowable threshold
for the programmed cell model.
Verify chlorinator readings Verify cell programming
Step 4C
Step 4D
After a short delay, new readings should appear on the Verify model number of installed cell. To verify, press
display. These readings reflect the active information the 'Menu' until 'Configuration Menu' appears. Press
related to the chlorinator circuit. IF the ProLogic is (>) one time, followed by (+). Press (>) two times to
reporting a voltage of 35V or higher, replace the main display 'Cell Type'. IF programmed cell does not match
board (see pg. 17). IF voltage is under 35V, proceed to model, use (+)/(-) to change. IF correct, contact tech
step 4D. support (908) 355.7995.
NOTE: The chlorinator circuit should never exceed 33Volts. If the voltage reads higher than 33V,
under the 'Diagnostic Menu' the main board will need to be replaced.
30
