RUGGEDCOM RST2228
Installation Guide
Figure 15: Assembling the Safety Cover
5.
Connect the ground terminal on the power source to the ground terminal on the device.
Figure 16: Chassis Ground Connection
1. M3 Screw 2. M3 Ring Lug
Section 2.5.3
Wiring Examples
The following illustrate how to connect single and dual power supplies to the device.
Wiring Examples
1
2
2
Chapter 2
Installing the Device
1
17
