Technical Information
PVG-EX 32 Proportional Valve Group

PVP Inlet Modules

12 | © Danfoss | June 2019
The PVG-EX 32 PVP inlet modules, also referred to as pump side modules, act as an interface between the
PVG-EX 32 proportional valve group and the hydraulic pump and tank reservoir.
PVP Inlet Module
Fixed displacement pump symbol
The PVP inlet module variants are based on a generic platform with a selection of additional features,
enabling you to tailor the PVP to suit the demands of any hydraulic system:
•
Open Center PVP on page 13 (for fixed displacement pumps)
•
Open Center PVP with PPRV
•
Open center PVP with HPCO and PVE PPRV
•
Closed Center PVP on page 22 (for variable displacement pumps)
•
Closed Center PVP with PPRV
•
Closed center PVPV with PPRV
•
Closed center PVPVM with PPRV
•
Open/Closed center PVP with PPRV
•
Open/Closed center PVPM
PVP inlet module dimensions
Weight: 3.1 kg [6.9 lb]
Variable displacement pump symbol
on page 16 (for fixed displacement pumps)
on page 19 (for fixed displacement pumps)
on page 24 (for variable displacement pumps)
on page 27 (for variable displacement pumps)
on page 29 (for variable displacement pumps)
on page 31
on page 34
23 [0.9]
95 [3.74]
110 [4.33]
BC290860493426en-000103
48 [1.89]
