Pressure Control Spools-Closed Neutral Position - Danfoss PVG-EX 32 Technical Information

Technical Information
PVG-EX 32 Proportional Valve Group
PVBS Main Spools Part Numbers
Pressure Control Spools—Closed Neutral Position
© Danfoss | June 2019
Schematic for PVBS without shuttle valve
Part numbers for Symmetric Pressure Control Spools
Part Number Actuation
PVE
157B7015
PVE
157B7010
PVE
157B9540
PVE
157B7011
PVE
157B7012
PVE
157B7013
PVE
157B7035
PVE
157B7030
PVE
11081829
PVE
157B7031
PVE
157B7032
PVE
157B7033
PVE
157B9683
PVH/PVHC
157B9015
PVH/PVHC
157B9010
PVH/PVHC
157B9540
PVH/PVHC
157B9011
PVH/PVHC
157B9012
PVH/PVHC
157B9013
Back pressure Pressure Control Spools (A/B->T flow track smaller than P->A/B)
Part Number Actuation
11177945
PVE
Schematic for PVBS with shuttle valve
PVB with
shuttle valve
A → T
- 5 [1,3]
- 10 [2,6]
- 18 [4,8]
- 25 [6,6]
- 40 [10,6]
- 65 [17,2]
Yes 5 [1,3]
Yes 10 [2,6]
Yes 18 [4,8]
Yes 25 [6,6]
Yes 40 [10,6]
Yes 65 [17,2]
Yes 100 [26,4]
- 5 [1,3]
- 10 [2,6]
- 18 [4,8]
- 25 [6,6]
- 40 [10,6]
- 65 [17,2]
PVB with
shuttle valve
A → T
- 40 [10,6]
Flow – l/min [US gal/min]
P → A P → B B → T
5 [1,3] 5 [1,3] 5 [1,3]
10 [2,6] 10 [2,6] 10 [2,6]
18 [4,8] 18 [4,8] 18 [4,8]
25 [6,6] 25 [6,6] 25 [6,6]
40 [10,6] 40 [10,6] 40 [10,6]
65 [17,2] 65 [17,2] 65 [17,2]
5 [1,3] 5 [1,3] 5 [1,3]
10 [2,6] 10 [2,6] 10 [2,6]
18 [4,8] 18 [4,8] 18 [4,8]
25 [6,6] 25 [6,6] 25 [6,6]
40 [10,6] 40 [10,6] 40 [10,6]
65 [17,2] 65 [17,2] 65 [17,2]
100 [26,4] 100 [26,4] 100 [26,4]
5 [1,3] 5 [1,3] 5 [1,3]
10 [2,6] 10 [2,6] 10 [2,6]
18 [4,8] 18 [4,8] 18 [4,8]
25 [6,6] 25 [6,6] 25 [6,6]
40 [10,6] 40 [10,6] 40 [10,6]
65 [17,2] 65 [17,2] 65 [17,2]
Flow – l/min [US gal/min]
P → A P → B B → T
65 [17,2] 65 [17,2] 65 [17,2]
