INTRODUCTION - POE GIGA-MCBASIC LFPT

ABOUT POE GIGA-MCBASIC LFPT

NOTE: Unless otherwise noted in this manual, any reference is applicable for both the 1x9 and SFP version
of the PoE Giga-McBasic LFPT.
The PoE Giga-McBasic is a solution for private network applications that
require Power-over-Ethernet (PoE) (IEEE802.3af) for installations inside
buildings where PoE is required to power an Ethernet device. The standalone
unit offers a model with one SFP or fixed fiber transceiver, 1x9, uplink for the
network connection, one PSE 10/100/1000Base-T copper port that provides
PoE and one 10/100/ 1000Mbps copper port, to connect a non-PoE unit to the
same fiber uplink. As a fiber-fed demarcation unit, it provides both power and
data to a remote device over a standard CAT5 copper line, eliminating the need
for a power connection to the remote device. The PoE Giga-McBasic LFPT
provides up to 15.4 Watts on one copper port and is powered by an internal
power supply, supporting 100-240 VAC. ( For more robust power requirements
on both copper ports, refer to the information about PoE+ Giga-McBasic LFPT.)
The SFP uplink can support fiber or copper SFPs. The fiber SFP, available in
SC or LC connectors, supports 100FDX or 1000FDX; a copper SFP supports
the SGMII interface (10/100/1000Mbps). The SFP, with or without DDMI, is
available for purchase from B+B SmartWorx. The SFP must be MSA-
compliant.
Copper ports auto-negotiate to the connected device's speed and duplex mode:
10 Mbps, 100 Mbps or 1000 Mbps, and HDX or FDX (including Flow Control).
The PoE+ Giga-McBasic LFPT supports jumbo frames up to 10240.
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.
