- Page 1 Giga-MiniMc 856-10730-TX & 856-10730-RX USER MANUAL...
- Page 2 Giga-MiniMc (-TX & -RX) Advantech B+B SmartWorx - Americas 707 Dayton Road Ottawa, IL 61350 USA Phone (815) 433-5100 (815) 433-5105 Advantech B+B SmartWorx - Europe Westlink Commercial Park Oranmore, Co. Galway, Ireland Phone +353 91-792444 Fax +353 91-792445 www.advantech-bb.com...
-
Page 3: Table Of Contents
Giga-MiniMc (-TX & -RX) CONTENTS Introduction – Giga-MiniMc (-TX & -RX) ............. 4 Installation ........................4 Hardware Mounting ...................... 4 Powering the Giga-MiniMc ................... 5 LED Operation - TX ...................... 6 LED Operation - RX ...................... 7 Specifications ........................ 8 B+B SmartWorx Technical Support ............ -
Page 4: Introduction - Giga-Minimc (-Tx & -Rx)
Giga-MiniMc (-TX & -RX) INTRODUCTION – GIGA-MINIMC (-TX & -RX) Part Numbers: 856-10730-RX, 856-10730-TX The above part numbers must be installed in pairs. As a pair, the units provide secure data to be passed in one direction only. The Giga-MiniMc provides a single conversion between 10/100/1000 Base-T twisted-pair and 1000 Base-SX/FX fiber. -
Page 5: Powering The Giga-Minimc
Giga-MiniMc (-TX & -RX) DIN Rail Clips Each Giga-MiniMc (-TX & -RX) unit can be mounted with two DIN Rail clips, optional hardware available from B+B SmartWorx). The DIN Rail clips include screws to allow the installation onto a DIN Rail. Install the screws into DIN Rail clips, which should be mounted perpendicular to the DIN Rail. -
Page 6: Led Operation - Tx
Giga-MiniMc (-TX & -RX) LED OPERATION - TX Each Giga-MiniMc includes two LEDs, located on the RJ-45 connector. LED functions are as follows for the TX unit: FX TX Glows green when a link is established on the FX (fiber) port; blinks green when FX LNK/ACT activity is detected on the fiber port. -
Page 7: Led Operation - Rx
Giga-MiniMc (-TX & -RX) LED OPERATION - RX Each Giga-MiniMc includes two LEDs, located on the RJ-45 connector. LED functions are as follows for the RX unit: Glows green when a link is established on the FX (fiber) port; blinks green when FX LNK/ACT activity is detected on the fiber port. -
Page 8: Specifications
Giga-MiniMc (-TX & -RX) SPECIFICATIONS Ethernet Connections • 10/100/1000 BaseT • Auto Negotiation • Auto Cross • Flow Control • 1536 MTU • Full Line-Rate Forwarding AC Wall Adapter 100 to 240 ±10% VAC Input, 5 VDC Output, 2A maximum Operating Temperature 0 to +50 °C (+32 to +122 °F) Storage Temperature... -
Page 9: B+B Smartworx Technical Support
Giga-MiniMc (-TX & -RX) B+B SM ARTWORX TECHNICAL SUPPORT USA/Canada: 1 (800) 346-3119 (Ottawa IL USA) Europe: +353 91 792444 (Ireland / Europe) Email: support@advantech-bb.com Web: www.advantech-bb.com... -
Page 10: Statements, Precautions, Guidelines, Regulatory
Giga-MiniMc (-TX & -RX) STATEMENTS, PRECAUTIONS, GUIDELINES, REGULATORY FCC RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A computing device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 11: Electrostatic Discharge (Esd) Precautions
Giga-MiniMc (-TX & -RX) ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS Electrostatic discharge (ESD) can cause damage to any product, add-in modules or stand alone units, containing electronic components. Always observe the following precautions when installing or handling these kinds of products. Do not remove unit from its protective packaging until ready to install. Wear an ESD wrist grounding strap before handling any module or component. -
Page 12: Regulatory, Standards, Compliances
© 2018 B+B SmartWorx – powered by Advantech. All rights reserved. The information in this document is subject to change without notice. B+B SmartWorx assumes no responsibility for any errors that may appear in this document.
