2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
LAN1
LAN2
ATX1
SCN1
SCN2
SCN3
SCN4
SDIMM1
Board and Pin Assignments
Description
COM4 Wafer Connector
COM3 Wafer Connector
Audio Connector
SMBus Connector
Digital I/O Connector
USB 2.0 Wafer Port 5 and 6
Fan Connector
2
I C Connector
Front Panel Connector
SATA Power Connector
COM1 Wafer Connector
SATA Connector
COM2 Wafer Connector
HDMI Connector
USB 3.0 Port 0 and 1
USB 3.0 Port 2 and 3
HDMI Connector
Ethernet Port 1
Ethernet Port 2
ATX Power Connector
Full-size PCI-Express Mini Card Connector
SIM Card Socket
Full-size PCI-Express Mini Card (USB) and mSATA Connector
eDP Connector
DDR3L SO-DIMM Connector
CAPA315 3.5" Board
11
