Proline Prosonic Flow 90U, 90W, 91W, 93C, 93U, 93W

Weight

Endress + Hauser
DN
EN EN EN
(DIN) (DIN) (DIN)
PN 6 PN 10 PN 16
[mm] [mm] [mm]
– – 900
– – –
– 1000 –
– – 1000
– – –
– – –
1200 – –
– 1200 –
– – 1200
– – –
– – –
1400 – –
– 1400 –
– – 1400
– – –
1600 – –
– 1600 –
– – 1600
– – –
1800 – –
– 1800 –
– – 1800
– – –
2000 – –
– 2000 –
– – 2000
– – –
The fitting length (L) is always the same per nominal diameter, regardless of the pressure rating selected.
Transmitter:
Wall-mount housing Prosonic Flow 90/93
•
Wall-mount housing Prosonic Flow 91
•
Measuring sensors:
Prosonic Flow W (clamp-on) incl. tensioning bands
•
Prosonic Flow U (clamp-on) incl. tensioning bands
•
Prosonic Flow W (Insertion / single-path version)
•
Prosonic Flow W (Insertion / dual-path version)
•
Sound velocity measuring sensors DDU 18 incl. tensioning bands
•
Wall thickness measuring sensor DDU 19 incl. tensioning band
•
A B
ANSI/
AWWA
[inch] [mm] [mm]
– 1012 894
36" 1016 898
– 1106 1004
– 1100 996
40" 1103 1000
42" 1147 1051
– 1282 1210
– 1277 1204
– 1270 1196
48" 1274 1200
54" 1399 1347
– 1453 1410
– 1448 1404
– 1441 1396
60" 1530 1500
– 1622 1608
– 1615 1600
– 1607 1590
66" 1655 1646
– 1793 1808
– 1786 1800
– 1776 1788
72" 1778 1790
– 1961 2004
– 1954 1996
– 1943 1984
80" 1949 1990
C L K
[mm] [mm] [mm]
464.9 1170 1125
467 1170 1168.4
522.1 1300 1230
517.9 1300 1255
520 1300 1289.05
546.5 1365 1346.2
629.2 1560 1405
626.1 1560 1455
621.9 1560 1485
624 1560 1511.3
700.4 1755 1682.75
733.2 1820 1630
730.1 1820 1675
725.9 1820 1685
780 1950 1854.2
836.2 2080 1830
832 2080 1915
826.8 2080 1930
855.9 2145 2032
940.2 2340 2045
936 2340 2115
929.8 2340 2130
930.8 2340 2197.1
1042.1 2600 2265
1037.9 2600 2325
1031.7 2600 2345
1034.8 2600 2362.2
6.0 kg
2.4 kg
2.8 kg
1 kg
4.5 kg
12.0 kg
2.4 kg
1.5 kg
