B. CP6000-EXT-SATA
B.1 Overview
The CP6000-EXT-SATA module (order no. CP6000-MK2.5SATA) has been designed for use
with the CP6000 6U CompactPCI board from Kontron Modular Computers and enables the
user to connect an onboard 2.5" Serial ATA hard disk to the CP6000.
B.2 Technical Specifications
Table B-1: CP6000-EXT-SATA Module Main Specifications
CP6000-EXT-SATA
Board-to-Board Connectors
Serial ATA Connector
Power Consumption
Temperature Range
Climatic Humidity
Dimensions
Board Weight
B.3

CP6000-EXT-SATA Module Functional Block Diagram

Figure B-1: CP6000-EXT-SATA Module Functional Block Diagram
J3 (CP6000-EXT-SATA)
ID 27942, Rev. 05
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Two 12-pin, male, board-to-board connectors, J1 and J3
One 22-pin Serial ATA connector, J2
3.3 V or 5 V, depending on the hard disk
Current 2.5" Serial ATA HDDs do not use 3.3 V.
Operating temp.: 0°C to +60°C
Storage temp.:
93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
54 mm x 27.5 mm
ca. 50 grams (without hard disk)
SATA Connectivity
J2 (CP6000-EXT-SATA)
2.5" HDD
SATA Signals
J30 (CP6000)
© 2005 Kontron Modular Computers GmbH
CP6000-EXT-SATA
SPECIFICATIONS
-55°C to +85°C
Power
J1 (CP6000-EXT-SATA)
J31 (CP6000)
Page B - 3
