Configuration
4.3

Onboard PCI Interrupt Routing

The 6300ESB provides up to 8 PCI and 4 PCI-X interrupt inputs. The table below describes the
connection of these IRQ signals.
For more information, refer to the INTEL 6300ESB data sheet.
Table 4-13: PCI Interrupt Routing
6300ESB IRQ INPUT
PIRQA
PIRQB
PIRQC
PIRQD
PIRQE
PIRQF
PIRQG
PIRQH
PCIXIRQ0
PCIXIRQ1
PCIXIRQ2
PCIXIRQ3
For more information, refer to the INTEL 6300ESB data sheet.
Page 4 - 10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
PCI DEVICE
VGA
Free
Free
Free
CPCI
CPCI
CPCI
CPCI
Gigabit front / PMC INTA
Gigabit rear / PMC INTB
Gigabit rear / PMC INTC
Gigabit front / PMC INTD
© 2005 Kontron Modular Computers GmbH
FUNCTION INTERNAL 6300ESB
USB A controller
SMBUS
SATA
USB B controller
Free
Free
Free
USB 2.0 controller
Free
Free
Free
Free
CP6000
ID 27942, Rev. 05
