Objectives and performance scope of the data interface
● Enumeration value
● Hardware:
– Station, slave (central, slave)
– Subnetwork, bus (global subnet)
Exceptions
The following graphic data is ignored after the import in PAA:
● No import of the graphical arrangements of the hardware configuration in HW Config of
STEP 7.
● No import of the graphical display of CFC and function diagrams.
Plugins
The following plugins are available to you in the menu "Plugins > Automation > PCS 7 interface":
Name
"Import / Export PCS 7"
"Type configurator"
"Connection manager"
"Excel import"
"Types re-assignment"
"HW configuration tool"
"NE 150 import"
"Import GSD[ML] files"
"Assign GSDs"
14
Icon Usage
See also chapters Import from PCS 7 to
PAA (Page 175) and Export from PAA to
PCS 7 (Page 165).
See also chapters Management of con‐
trol module types (Page 25) and Type
configurator plugin (Page 59).
See also chapter Creating and editing
large quantity of connections
(Page 155).
See also chapter Objective of Excel im‐
port (Page 71).
See also chapter Synchronizing CM var‐
iants (Page 31)
See also chapter HW configuration tool
(Page 120)
See also chapter NE 150 import
(Page 55)
See also chapter Importing GSD /
GSDML files (Page 93)
See also chapter Assigning GSD ob‐
jects (Page 98)
