Clarus SQ 8 MS Hardware Guide
Figure 9 Pulling back the inner transfer tube. Figure 9 Pulling back the inner transfer tube.
5. Open the Clarus SQ 8 MS access door.
6. Hold the source by the edge and rotate it counter clockwise.
Access Door Access Door
Figure 10 Rotating Figure 10 Rotating the sour
7. Carefully pull out the source.
72
Inner Transfer Tube Inner Transfer Tube
Pull Back Pull Back
1/4-inch Nut 1/4-inch Nut
the source. ce.
Column Column
Source Source
