Pre-Installation Requirements

Laboratory Space Requirements

Size Size
Clarus SQ 8 T, C, and S 32 cm (13 in.) wide x 50 cm
MS (20 in.) high x 77 cm (30 in.) deep
Clarus 580 GC 32 cm (13 in.) wide x 46 cm
(18 in.) high x 77 cm (30 in.) deep
Forepump 30.5 cm (12 in.) wide x 44 cm (17.3
in.) high x 72 cm (28.4 in.) deep.
Clarus 680 GC 99 cm (39 in.) wide x 53 cm
(21 in.) high x 82 cm (32 in.) deep
Autosampler Tower 13 cm (5 in.) wide x 36 cm (14 in.)
high x 24 cm (9.5 in.) deep
Physical Configuration Single unit for use on standard laboratory bench that can be
interfaced to a computer and printer.
Peripherals, Printers etc. Allow at least 94 cm (36 in.) on either side of the GC/MS
to accommodate additional equipment (for example, the
computer).
Warnings and Safety Information
Weight Weight
46.8 kg (102 lb)
48 kg (105 lb)
25.9 kg (57 lb)
49 kg (108 lb)
4.5 kg (10 lb)
