5.1.21 23-** Time Based Funtions

Param Parameter description
eter #
23-0* Timed Actions
23-00 ON Time
23-01 ON Action
23-02 OFF Time
23-03 OFF Action
23-04 Occurrence
23-0* Timed Actions Settings
23-08 Timed Actions Mode
23-09 Timed Actions Reactivation
23-1* Maintenance
23-10 Maintenance Item
23-11 Maintenance Action
23-12 Maintenance Time Base
23-13 Maintenance Time Interval
23-14 Maintenance Date and Time
23-1* Maintenance Reset
23-15 Reset Maintenance Word
23-16 Maintenance Text
23-5* Energy Log
23-50 Energy Log Resolution
23-51 Period Start
23-53 Energy Log
23-54 Reset Energy Log
23-6* Trending
23-60 Trend Variable
23-61 Continuous Bin Data
23-62 Timed Bin Data
23-63 Timed Period Start
23-64 Timed Period Stop
23-65 Minimum Bin Value
23-66 Reset Continuous Bin Data
23-67 Reset Timed Bin Data
23-8* Payback Counter
23-80 Power Reference Factor
23-81 Energy Cost
23-82 Investment
23-83 Energy Savings
23-84 Cost Savings
MG11CE02
Programming Guide
0 N/A All set-ups
999999.999 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value 4 set-up
ExpressionLimit 2 set-ups
[0] Disabled 2 set-ups
ExpressionLimit 2 set-ups
[1] No action 2 set-ups
[0] All days 2 set-ups
[0] Timed Actions
Auto 2 set-ups
[1] Enabled 2 set-ups
[1] Motor bearings 1 set-up
[1] Lubricate 1 set-up
[0] Disabled 1 set-up
1 h 1 set-up
ExpressionLimit 1 set-up
[0] Do not reset All set-ups
0 N/A 1 set-up
[5] Last 24 Hours 2 set-ups
ExpressionLimit 2 set-ups
0 N/A All set-ups
[0] Do not reset All set-ups
[0] Power [kW] 2 set-ups
0 N/A All set-ups
0 N/A All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Do not reset All set-ups
[0] Do not reset All set-ups
100 % 2 set-ups
1 N/A 2 set-ups
0 N/A 2 set-ups
0 kWh All set-ups
0 N/A All set-ups
