EUT Supply Specifications

Standard models
Model CDN
compact NX5 300V
EUT Fuse
The compact NX5 models have no internal fuse for the EUT supply.
The user is responsible to adapt a suitable fuse for the EUT outside the compact NX5
6.6.

General Specifications

Mains supply
Power consumption
Fuse
Safety
Safety circuit
Warning lamp
Design
Interfaces
Serial interface
LAN
SYS link IN, OUT
Analog output
EUT1, EUT 2 input
Digital input
Trigger level
Input impedance
Max. Input voltage
Dimensions
Weight
6.7.

Environmental conditions

Temperature
Humidity
Atmospheric pressure
=> Not relevant data for the standards can be changed by the manufacturer <=
Operating Manual
Remarks
16A 1- phase DC 300 V / 16 A
85 to 264 Vac, 50/60Hz
75 W
2 x 2 AT slow blow
External interlock capability
voltage free contact max. 60 V 2 A
As per IEC 1010, EN 61010
1 x USB A front side for memory stick
1 x USB A rear side
1 x USB B
1x opto-link
Ethernet
26 pin high density Sub D to control external devices
0-10V DC, to control an external power supply
+ 15 V to 0 V, negative slope to zero
2 V ±1 V
> 10 kΩ
+ 15 V
compact NX5
19" / 3 HU
app. 25 kg
10 °C to 35 °C
30 % to 70 %; non condensing
86 kPa (860 mbar) to 106 kPa (1 060 mbar)
